Ransburg REM Automatic Applicator 73499 - Manual (Page 36)

AA-87-02.3 3 1 3 1 3 1 3 1 3 1
REM Automatic Applicator - Parts Identification
50 Fitting, 1/4” Tube X 1/8” NPT, Trigger 7884-02
51 Fitting, 3/8” Tube X 1/4” NPT, Assist Air 7884-03
52 Bracket, Fluid Line 74088-00
53 Screw, Socket Head (2 Required) 8212-16F
54 Lock Washer (2 Required) 7734-04
55 Fluid Line Support 72367-00
56 Screw Pan Head 72406-04
57 Valve Assembly, Air Assist Complete (Includes Items 58 - 62) 18851-00
58 Knob, Control 18840-00
59 Nut Retaining 18853-00
60 * O-Ring 13076-08
61 Washer (2 Required) 18833-00
62 Spring 18829-00
63 Needle 18852-00
64 * Gasket 72375-02
65 Connector, Fluid 74085-00
66 * O-Ring 72209-02
67 Nut, Union 72357-01
68 Elbow Connection 74086-00
69 Fluid Tube 74087-00
70 Fitting, Fluid 72381-01
71 Nut, Fitting Fluid 72382-01
72 Screw, Pan Head 73490-01
73 * O-Ring 7554-12
74 *** Fluid Filter 72400-00
75 Fluid Connection Tool 74258-00l
76 T-Handle Tool 20049-00
77 Nozzle Tool 72468-00
Item # Item # Item # Item # Item #
REM AUT REM AUT REM AUT REM AUT REM AUTOMA OMA OMA OMA OMATIC APPLICA TIC APPLICA TIC APPLICA TIC APPLICA TIC APPLICAT T T T TOR - P OR - P OR - P OR - P OR - PAR AR AR AR ARTS LIST TS LIST TS LIST TS LIST TS LIST (Figure 2) (Figure 2) (Figure 2) (Figure 2) (Figure 2)
Description Description Description Description Description
** Dash number (-XX) reads in feet except 99 which = 100 feet (i.e. -36 = 36 feet). These items are
availble in standard lengths of 36, 50, 75, and 100 feet. When ordering High Voltage Cable, use footage
for -xx.
*** Dash number (-XXXX) indicates Fluid Nozzle configuration. See “Nozzle Selection Chart” in the
“Operation” section for Nozzle Specifications and Order Number Identification.
**** The configuration and number identification of this filter may change. When you order a 72400
Filter, your ITW Ransburg distributor will provide the current configuartion.
High Voltage Test Assembly Applicator Output
Tester Transformer Output
72453-00 REP 72453-00 REP 72453-00 REP 72453-00 REP 72453-00 REPAIR KIT AIR KIT AIR KIT AIR KIT AIR KIT
74150-02
74195-00
Part # Part # Part # Part # Part # Description Description Description Description Description
Note: Includes items indicated * on the “REM Automatic Applicator Exploded View Parts List”.
Part # Part # Part # Part # Part #
