AA-87-02.3

2 0

2 0

2 0

2 0

2 0

REM Automatic Applicator - Maintenance

SERVICE

SERVICE

SERVICE

SERVICE

SERVICE

Because we want to provide our users with the
most up-to-date technology possible, we are
constantly seeking to improve products. If a
change in product configuration occurs after it is
on the market, we will implement that technology
in future production and if practical, make it
available to current users. The following service
information is based on standard specifications
and procedures for this product. If you find some
minor deviations between this information and your
equipment because of design or manufacturing
changes, contact your ITW Ransburg
representative to resolve the differences.

SERVICE PROCEDURES

SERVICE PROCEDURES

SERVICE PROCEDURES

SERVICE PROCEDURES

SERVICE PROCEDURES

Al repairs should be made on a clean, flat surface.
If a vise is used to hold parts during service or
repair, DO NOT clamp onto plastic parts and
always pad the vise jaws!

Apply a heavy coat of 59972-00 Dielectric grease
to the following parts when assembling:

• Needle Shaft Assembly [7 - 15] External

• Tube, Packing Internal [12]

• Transformer Assembly [44] connection to Body

Assembly [25]

• Externally to contact surface of Low Voltage

Cable and Transformer

Apply 7969-00 Sealant to the following parts when
assembling:

• External to contact surface of Piston/Valve and

Body Assembly [25]

• External to threads of Piston Housing [39]

• Set Screws [43]

>

ALWAYS

ALWAYS

ALWAYS

ALWAYS

ALWAYS remove the applicator from

the work site for service or repair.

C A U T I O N

C A U T I O N

C A U T I O N

C A U T I O N

C A U T I O N

!!!!!

>

DO

DO

DO

DO

DO NOT USE

NOT USE

NOT USE

NOT USE

NOT USE any silicone lubrication

in this system.

C A U T I O N

C A U T I O N

C A U T I O N

C A U T I O N

C A U T I O N

!!!!!

Equipment Required:

• Gun Spanner (3 in 1 Nozzle Wrench) * for Barrel

Nut [19] and Packing Nut [16]

• Nozzle Tool * for Fluid Nozzle [3]

• 3/16” Allen Wrench for Hose Fittings

• Open End Wrenches: 9mm (2 Required),

15/16”, 7/8”, 11/16”, 9/16”, 7/16”, 3/4”, 3/8”
(2 Required), and 1/4”

• Screwdriver (broad)

• Dielectric Grease *

• Sealant *

• Plastic or Wood Dowel Rod, 5/16-inch diameter

• 3/8” Nut Driver

• Hook Tool (Dental Pick)

• T-Handle Tool (for Valve Body Service) [33]

• 3/32” Allen Wrench for Set Screws

* See “Parts Identification” section for part number.

ARCHIVE
