3. Screw two (2) eyebolts into the threaded adapters in the platform top and use a
forklift or other lifting means along with chains, cables, or nylon straps to remove
the scale from the crate.
4. Set the scale so that the interface cable exits in a direction where it can be
protected. If possible, use a cable protector to reduce 'trip' hazards and to protect
the interface cable from being damaged.
5. Level the scale by turning the foot pads.
6. Wire the scale cable to the proper type indicator as follows:
i. Analog Interface (Junction Box 67171):
L/C Wire Color Function Analog Instrument
Black (-) Excitation (-) Excitation
Green (+) Excitation (+) Excitation
Yellow Shield Shield
White (+) Signal (+) Signal
Red (-) Signal (-) Signal
51103 8 01/07 -- Rev. 1
NOTE: The analog junction box and the QMB interface box on the Lift Deck models are
mounted remotely on a wall location. The boxes must be located above the splash
line and in a secure area away from material handling traffic.
CAUTION: Do NOT use grab or slip hooks to lift the scale. Failure to use the proper
lifting tools may result in personal injury.
