10. Load Cell Specifications:
Specifications Stainless Steel
Material: Stainless Steel 17-4ph
Resistance: 1000 Ohm
Rated Output: 2 mV/V
Safe Overload: 150%
Compensated Temp range: -10ºC to 40ºC
Safe Operating Temp range: -18ºC to 65ºC
B. Analog Junction Box and Optional QMB PCB Replacement:
1. Remove power to the indicator.
2. Open the platform access cover, then the box cover.
3. Loosen all gland bushing nuts.
4. Check that all load cells have wire markers on the cable ends. If not, identify cells
with wire markers or other means, then disconnect the load cells' wires from the
terminal blocks. Disconnect the home-run wires.
5. Remove the PCB, clean the box, then install the new PCB.
6. Reconnect all load cell and home-run wires to the new PCB.
7. Tighten all gland bushing nuts.
8. Replace the box cover and torque all screws to 18-20 in/lbs. Replace the platform
access cover.
9. Recalibrate as necessary.
51103 15 01/07 -- Rev. 1
NOTE: For analog systems, leave the box cover removed until all corner adjustments are
completed.
