A. Introduction:
The Aegis Stainless Steel floor scale features a rugged structural rib design and a
nominal height of three inches -- among the lowest in the industry. With a full range of
accessories, these scales can be configured to fit most floor scale applications.
B. Description:
The Aegis Industrial Stainless Steel series floor scale platform is fully assembled and
pre-wired. Aegis stainless steel floor scale sizes range from 30" x 30" to 6' x 8', and
have capacities from 1000 to 10,000 lbs.
The Aegis Lift Deck Floor Scale is another addition to Fairbanks’ Aegis line of floor
scales. It is designed to offer a safe and convenient way to lift the deck of the scale to
facilitate cleaning. The Aegis Lift Deck Floor Scale is for pit installation only.
The Aegis floor scales use a standard summing junction box to interface with analog
indicators, and is equipped with a 25' interface cable. Junction boxes are constructed
of stainless steel, and all models have threaded holes in the decks for attaching
eyebolts to facilitate installation and cleaning.
C. Specifications:
Models and sizes are included in a chart in Appendix
II.
Description Aegis Stainless Steel
Platform deck plate 0.25”
Platform height 3.0”
Operating temperature 15º to 104º F
-10º to 40º C
Humidity 100% suitable for water washdown
Overload capacity 150% of rated capacity
Endloading capacity 100% of rated capacity
Construction Type 304 stainless steel
Grade level Within 3º of level
