Fairbanks Aegis Industrial Stainless User Manual
Page 19
B. Stainless Steel Lift Deck Platforms:
Item
Part#
Description
Models
1 See
Appendix
I Platform Weldment
See Appendix
I
2
23426
Load Cell, 1K
1K, 2.5K
2
23427
Load Cell, 2.5K
5K
2
23428
Load Cell, 5K
10K
3
66754
Load Cell Shim
ALL
4
63899
Foot Assembly
ALL
5
54503
Load Cell Mtg Bolt ½'-20 x 1 ¾" ALL
*
67171
Analog Junction Box
ANALOG
*
96141
PCB for Analog box
ANALOG
*
23902
J-Box, Remote Cradle Bracket
ANALOG
*
15291
QMB Junction Box (optional)
INTALOGIX™
*
15635
PCB for QMB Box (optional)
INTALOGIX™
*
24176
J-Box, Remote Cradle Bracket
INTALOGIX™
7
23429
Gas Spring, 250 lb
ALL
8
23436
Ball Stud
ALL
9
23437
Safety Clip
ALL
10
11121
Flat Washer .31
ALL
11
11105
Hex Nut .31-18
ALL
12
13
23834
Label, Pinch Point
ALL
14
23836
Label, Lifting Hazard
ALL
15
11224
Label, Fairbanks
ALL
16
17613
Wire Tie
ALL
17
18
Serial Tag
Individual
* Not shown on parts diagram.
51103
19
