Appendix C Parameters for Data Monitoring and Logging
66 Multi-Mon Multiple Circuit Energy Monitor
Designation Designation Designation Designation Description Description Description Description
V23 V23 Voltage
V31 V31 Voltage
AVR TOTAL AVR TOTAL AVR TOTAL AVR TOTAL 1 1 1 1----Second Total Values Second Total Values Second Total Values Second Total Values 1
kW Total kW
kvar Total kvar
kVA Total kVA
PF Total PF
PF LAG Total PF lag
PF LEAD Total PF lead
kW IMP Total kW import
kW EXP Total kW export
kvar IMP Total kvar import
kvar EXP Total kvar export
AVR AUX AVR AUX AVR AUX AVR AUX 1 1 1 1----Second Auxiliary Values Second Auxiliary Values Second Auxiliary Values Second Auxiliary Values 1
In In (neutral) Current
FREQ Frequency
DEMANDS DEMANDS DEMANDS DEMANDS Present Demands Present Demands Present Demands Present Demands 1
V1 DMD V1 Volt demand
V2 DMD V2 Volt demand
V3 DMD V3 Volt demand
I1 DMD I1 Ampere demand
I2 DMD I2 Ampere demand
I3 DMD I3 Ampere demand
kW IMP SD kW import sliding window demand
kW EXP SD kW export sliding window demand
kvar IMP SD kvar import sliding window demand
kvar EXP SD kvar export sliding window demand
kVA SD kVA sliding window demand
kW IMP ACC DMD kW import accumulated demand
kW EXP ACC DMD kW export accumulated demand
kvar IMP ACC DMD kvar import accumulated demand
kvar EXP ACC DMD kvar export accumulated demand
kVA ACC DMD kVA accumulated demand
kW IMP PRD DMD kW import predicted sliding window demand
kW EXP PRD DMD kW export predicted sliding window demand
kvar IMP PRD DMD kvar import predicted sliding window demand
kvar EXP PRD DMD kvar export predicted sliding window demand
kVA PRD DMD kVA predicted sliding window demand
SUMM ACC DMD SUMM ACC DMD SUMM ACC DMD SUMM ACC DMD Summary (TOU Total) Accumulated Demands Summary (TOU Total) Accumulated Demands Summary (TOU Total) Accumulated Demands Summary (TOU Total) Accumulated Demands
SUM REG1 ACC DMD Summary register #1 demand
SUM REG2 ACC DMD Summary register #2 demand
SUM REG3 ACC DMD Summary register #3 demand
SUM REG4 ACC DMD Summary register #4 demand
SUMM SW DMD Summary (TOU Total) Sliding Demands Summary (TOU Total) Sliding Demands Summary (TOU Total) Sliding Demands Summary (TOU Total) Sliding Demands 1
SUM REG1 SW DMD Summary register #1 demand
SUM REG2 SW DMD Summary register #2 demand
SUM REG3 SW DMD Summary register #3 demand
SUM REG4 SW DMD Summary register #4 demand
ENERGY ENERGY ENERGY ENERGY Total Energy Total Energy Total Energy Total Energy 1
kWh IMPORT kWh import
kvarh IMPORT kvarh import
kWh EXPORT kWh export
kvarh EXPORT kvarh export
kVAh TOTAL kVAh total
SUMMARY REGS SUMMARY REGS SUMMARY REGS SUMMARY REGS Summary (TOU Total) Energy Registers Summary (TOU Total) Energy Registers Summary (TOU Total) Energy Registers Summary (TOU Total) Energy Registers 1
SUM REG1 Summary energy register #1
SUM REG2 Summary energy register #2
SUM REG3 Summary energy register #3
SUM REG4 Summary energy register #4
MAX DMD MAX DMD MAX DMD MAX DMD Maximum Demands Maximum Demands Maximum Demands Maximum Demands
V1 DMD MAX V1 Maximum volt demand
V2 DMD MAX V2 Maximum volt demand
V3 DMD MAX V3 Maximum volt demand
I1 DMD MAX I1 Maximum ampere demand
I2 DMD MAX I2 Maximum ampere demand
I3 DMD MAX I3 Maximum ampere demand
kW IMP SD MAX Maximum kW import sliding window demand
kW EXP SD MAX Maximum kvar import sliding window demand
