Electro Cam 5000 Series - Manual (Page 66)

60 59.1
61 60.5
62 61.9
64 63.3
65 64.7
66 66.1
68 67.5
70 68.9
71 70.3
72 71.7
74 73.1
75 74.5
76 75.9
78 77.3
80 78.8
81 80.2
82 81.6
84 83.0
85 84.4
86 85.8
88 87.2
89 88.6
90 90.0
91 91.4
92 92.8
94 94.2
95 95.6
96 97.0
98 98.4
100 99.8
101 101.3
102 102.7
104 104.1
105 105.5
106 106.9
108 108.3
110 109.7
111 111.1
112 112.5
114 113.9
115 115.3
116 116.7
118 118.1
120 119.5
121 120.9
122 122.3
124 123.8
125 125.2
126 126.6
128 128.0
130 129.4
131 130.8
132 132.2
134 133.6
135 135.0
136 136.4
138 137.8
140 139.2
141 140.6
142 142.0
144 143.4
145 144.8
156 146.3
148 147.7
150 149.1
151 150.5
152 151.9
154 153.3
155 154.7
156 156.1
158 157.5
160 158.9
161 160.3
162 161.7
164 163.1
165 164.5
166 165.9
168 167.3
170 168.8
171 170.2
172 171.6
174 173.0
175 174.4
176 175.8
178 177.2
179 178.6
240 239.1
241 240.5
242 241.9
244 243.3
245 244.7
246 246.1
248 247.5
250 248.9
251 250.3
252 251.7
254 253.1
255 254.5
256 255.9
258 257.3
260 258.8
261 260.2
262 261.6
264 263.0
265 264.4
266 265.8
268 267.2
269 268.6
270 270.0
271 271.4
272 272.8
274 274.2
275 275.6
276 277.0
278 278.4
280 279.8
281 281.3
282 282.7
284 284.1
285 285.5
286 286.9
288 288.3
290 289.7
291 291.1
292 292.5
294 293.9
295 295.3
296 296.7
298 298.1
300 299.5
301 300.9
302 302.3
304 303.8
305 305.2
306 306.6
308 308.0
310 309.4
311 310.8
312 312.2
314 313.6
315 315.0
316 316.4
318 317.8
320 319.2
321 320.6
322 322.0
324 323.4
325 324.8
326 326.3
328 327.7
330 329.1
331 330.5
332 331.9
334 333.3
335 334.7
336 336.1
338 337.5
340 338.9
341 340.3
342 341.7
344 343.1
345 344.5
346 345.9
348 347.3
350 348.8
351 350.2
352 351.6
354 353.0
355 354.4
356 355.8
358 357.2
359 358.6
180 180.0
181 181.4
182 182.8
184 184.2
185 185.6
186 187.0
188 188.4
190 189.8
191 191.3
192 192.7
194 194.1
195 195.5
196 196.9
198 198.3
200 199.7
201 201.1
202 202.5
204 203.9
205 205.3
206 206.7
208 208.1
210 209.5
211 210.9
212 212.3
214 213.8
215 215.2
216 216.6
218 218.0
220 219.4
221 220.8
222 222.2
224 223.6
225 225.0
226 226.4
228 227.8
230 229.2
231 230.6
232 232.0
234 233.4
235 234.8
236 236.3
238 237.7
PLuS = Control Position Deg = Actual Degree Postion
PLuS Deg PLuS Deg PLuS Deg PLuS Deg PLuS Deg PLuS Deg
60 Pulse Disc Setpoints for Encoder Based Controls
Appendix A-15
Encoder Position Chart / 60 Pulse Disc for Encoder Based Controls
16. 90 92
17. 96 100
18. 102 105
19. 108 111
20. 115 118
21. 121 124
22. 126 130
23. 132 135
24. 140 142
25. 145 148
26. 151 154
27. 156 160
28. 164 166
29. 168 171
30. 174 176
31. 179 181
32. 185 188
33. 191 194
34. 196 200
35. 204 206
36. 210 212
37. 215 218
38. 221 224
39. 228 231
40. 234 236
41. 240 242
42. 245 248
43. 252 255
44. 258 261
45. 264 266
1. 0 2
2. 6 10
3. 12 15
4. 18 21
5. 25 28
6. 31 34
7. 36 40
8. 42 45
9. 50 52
10. 55 58
11. 61 64
12. 66 70
13. 74 76
14. 80 82
15. 85 88
Pulse ON OFF Pulse ON OFF Pulse ON OFF Pulse ON OFF
46. 269 271
47. 275 278
48. 281 284
49. 286 290
50. 294 296
51. 300 302
52. 305 308
53. 311 314
54. 318 321
55. 324 326
56. 330 332
57. 335 338
58. 342 345
59. 348 351
60. 354 356
0 0.0
1 1.4
2 2.8
4 4.2
5 5.6
6 7.0
8 8.4
10 9.8
11 11.3
12 12.7
14 14.1
15 15.5
16 16.9
18 18.3
20 19.7
21 21.1
22 22.5
24 23.9
25 25.3
26 26.7
28 28.1
30 29.5
31 30.9
32 32.3
34 33.8
35 35.2
36 36.6
38 38.0
40 39.4
41 40.8
42 42.2
44 43.6
45 45.0
46 46.4
48 47.8
50 49.2
51 50.6
52 52.0
54 53.4
55 54.8
56 56.3
58 57.7
This table shows how an encoder based PLuS control scales 256 increments into degrees. Each increment
change is equal to exactly 1/256th of a revolution (approximately 1.4 degrees) even though the position
displayed sometimes changes by 2 degrees for a 1 increment change in position (control skips 3s, 7s & 9s).
