Figure 4.3: Range Options List Box
To Set the ranges to values different than the default, click on ‘Set
Range’ and the Set Range screen will pop up.
Figure 4.4: Range Setup Screen
The first screen allows you to set range 1. If you click on the Range
button, it will take you to the setup of range 2. Click Range again will
take you to the setup of range 3, then range 4, then back again to range
1. Note that ranges and alarms are set in ppb units.
Note: The ranges must sequentially increase from low to high, for
example, if range 1 is set as 0–100 ppb and range 2 is set
Set Range 1 Limit
Upper Limit PPB
100
UP DN RANGE
OK CANCEL
