Operation

Teledyne Analytical Instruments 39

-----------------------

ANALOG-OUT

ADJUST

-----------------------

CH1 mA Offset: 0

CH1 mA Gain: 0

CH1 Select: THC

CH2 Select: WAVE

-----------------------

CHANGE

STREAM

-----------------------

CHANGE STREAM NOT AVAILABLE

-----------------------

TIMING

-----------------------

THC I/P: 100%/00%

THC TIME: 05m00s

THC I Begin: 00m05s

THC I End: 00m05s

AIR I Begin: 00m05s

AIR I End: 00m05s

THC Base 1: 00m03s

THC Base 2: 00m03s

SMP I/P: 100%/00%

SMP

TIME:

05m00s

SMP I Begin: 00m05s

SMP I End: 00m30s

SMP Base 1: 00m03s

SMP Base 2: 00m03s
