MODEL 2230R, Process Hydrogen Analyzer
Page 19
Now use the 4 BIT-TO-HEXADECIMAL table above to convert this 4 bit value combination into a
two place hexadecimal value:
Two Place Hexadecimal Value : 8b
From the OPTIONS table above, you identify your desired columns with its corresponding
bit value:
Descriptions Bit Value
Calculations Errors 0000 0100
Heater State 0000 0010
4 Bit Value Combination: 0000 0110
Again, use the 4 BIT-TO-HEXADECIMAL table to convert this 4 bit value combination into a two
place hexadecimal value:
Two Place Hexadecimal Value : 06
Conclusion: To have the Time Stamp, Capacitor Reading, Overall Hydrogen Reading, the Peak
Hydrogen Reading, Calculations Errors and Heater State columns continuously reported, you
will implement the “G” serial command (“Go” Command, refer to LEVEL 1 COMMANDS table) as
follows at the H2scan:
command prompt: G < fmt> = g 8b 06
Display User Response
H2scan: Type “g 8b 06”
