15
BOSCH
ENG
lISH
Important
Open out the first page of the booklet, this will
help you to understand how the appliance works.
This appliance complies with international safety
standards.
This appliance has been designed exclusively for
domestic use and must not be used for industrial
purposes.
This appliance must be used only for the
purposes for which it was designed, i.e. as an
iron. Any other use will be considered improper
and consequently dangerous. The manufacturer
will not be held responsible for any damage
arising from misuse or improper use.
General safety instructions
• The iron must not be left unattended while it is connected to the
supply mains.
• Remove the plug from the socket before filling the appliance with
water or before pouring out the remaining water after use.
• The appliance must be used and placed on a stable surface.
• When placed on its stand, make sure that the surface on which the
stand is placed is stable.
• The iron should not be used if it has been dropped, if there are
visible signs of damage or if it is leaking water. It must be checked
by an authorized Technical Service Centre before it can be used
again.
• With the aim of avoiding dangerous situations, any work or repair
that the appliance may need, e.g. replacing a faulty mains cable,
must only be carried out by qualified personnel from an Authorised
Technical Service Centre.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
• Keep the iron and its cord out of reach of children less than 8 years
of age when it is energized or cooling down.
• CAUTION. Hot surface.
Surface is liable to get hot during use.
Description
1. Water tank
2. Removable iron pad
3. Steam hose storage fixing
4. “Calc’n’Clean Advanced” scale collector
5. Mains cable storage compartment
6. Mains cable
7. Steam hose
8. “Energy Saving” button *
9. “Steam ready” / “Auto shut-off*” pilot light
10. “on / off” pilot light *
11. Variable steam control *
12. “Refill water tank” / “Clean warning” pilot light*
13. Main power switch (0/I)
14. Iron fixation system “SecureLock”
15. Housing with internal steam generator
16. Temperature control knob
17. Steam release button
18. Steam shot button “Ultimate” *
19. Iron pilot light
20. Soleplate
21. Fabric-protection soleplate cover*.
* model dependent
a
preparations
1. Release the iron from its lock system (14) by
pulling the lever located at the heel of the iron
backwards.
2. Remove any label or protective covering from
the soleplate.
3. Place the appliance horizontally on a solid,
stable surface. You may remove the iron pad
from the appliance and place the iron on it on
another solid, stable, horizontal surface.
4. Fill the water tank, making sure not to pass the
level mark.
5. Unwind the mains cable (6) fully and plug it into
an earthed socket.
6. Set the main power switch (13) to the on
position.
7. The “Steam ready” indicator lamp (9) will light
up after several minutes, indicating that the
appliance is ready to use.
The steam generator will take more time to
reach “Steam ready” state only upon the initial
heating up, or after performing the de-scaling
operation (Calc’n’Clean).
When water is already present in the steam
generator during regular use, heat up time to
reach the operating temperature will be faster.
• This appliance is to be connected and used in
accordance with the information stated on its
characteristics plate.
• This appliance must be connected to an
earthed socket. If it is absolutely necessary to
use an extension cable, make sure that it is
suitable for 16A and has a socket with an earth
connection.
• If the safety fuse fitted in the appliance blows,
the appliance will be rendered inoperative. To
restore normal operation the appliance will
have to be taken to an authorised Technical
Service Centre.
• In order to avoid that, under unfavourable
mains conditions, phenomena like transient
voltage drops or lighting fluctuations can
happen, it is recommended that the iron is
connected to a power supply system with a
maximum impedance of 0.27Ω . If necessary,
the user can ask the public power supply
company for the system impedance at the
interface point.
• The appliance must never be placed directly
under the tap to fill the water tank.
• Unplug the appliance from the mains supply
after each use, or if a fault is suspected.
• The electrical plug must not be removed from
the socket by pulling the cable.
• Never immerse the iron in water or any other
fluid.
• Do not leave the appliance exposed to weather
conditions (rain, sun, frost, etc.)
Important:
▪ This appliance reaches high temperatures and
produces steam during use, this could cause
scalds or burns if not used properly.
▪ The steam hose, base station, metal plate at
the bottom of the removable iron pad (2) and in
particular the iron can get hot when used. This
is normal.
▪ Never aim the steam at people or animals.
▪ Do not allow the power cable to come into
contact with the soleplate when it is hot.
▪ Be aware that the system can keep on
steaming for a short additional time after
releasing the steam trigger. This is a normal
function.
