Model No. CI-6460
Force Sensor Balance Stand
5
®
Setup Options
a) Mounting a Force Sensor
The Force Sensor Balance Stand can be used with three different PASCO force sensors (See
Figures 2a-2c below.)
b) Mounting both a Force and Acceleration Sensor
In addition, an acceleration sensor can be mounted to the stand to measure the angle of
incline. Depending on the force sensor used, the mounting position will vary. To mount an
acceleration sensor, use the bracket and screws provided with the acceleration sensor.
Figure 2a: Setup with a
PASPORT Force
Sensor (PS-2104)
Figure 2b: Setup with a
ScienceWorkshop
Force Sensor (CI-6537)
Figure 2c: Setup with
an Economy Force
Sensor (CI-6746)
3a) front view
bracket
3b) side view
Figure 3a-3b: Setup with a PASPORT Force Sensor (PS-2104) and Acceleration
Sensor (PS-2118)
