Model No. WA-9867 Specifications
9 ®
Sequence Start-over: When the last stored note has been played, the Sine Wave Generator wraps
around and starts over with the first note. At any time during play mode, a quick press of the Up
arrow key will cause the sequence to start over with the first note.
Stop Playback: Press and hold the Store/Exit key to return to normal mode. The output
frequency will be set to the stored increment.
The sequence remains in storage. You can go back to Advanced Mode and play the sequence
again, even if you turned the unit off and unplug it in the interim.
Specifications
Frequency 1 to 800 Hz
Adjustable in 0.1 Hz increments
Output DC coupled push-pull
Short-circuit protected
Amplitude 0 to 10 V peak (approx.)
Current >1 A into 8
Ω
load
Memory Up to 80 stored notes
Display 4 digit LED
Input Power 100–240 VAC, 50/60 Hz
Dimensions 12 Ч 11 Ч 5 cm
(not including separate power supply)
