B UILDING A PAGE
2. If the Home screen is not visible, select the Home button to return to
the Home screen.
A list of the spectrometer’s measurements appears on the Home screen.
Building a page
You can view spectrometer data as a function of wavelength (spectral scope
mode) or as a function of time (time acquisition mode). The two following
topics give instructions for building simple SPARKlab pages in both of these
modes.
Building a Spectral Scope Page
1. Select the Build button (if you are viewing the Home screen) or select
the New Page button (if you are viewing and existing SPARKlab page)
to open the Page-build screen.
Build button
New Page button
2. In the Page-build screen, select one of the following measurements:
• Intensity
• Minus Dark
• Absorbance
• Transmission
• Rel. Irradiance
See “About the measurements” below for information about each
measurement.
The selected measurement is highlighted in orange.
3. In addition to the measurement that you selected in the last step, select
the Wavelength measurement.
There should now be two measurements selected.
