Equipment
The ME-6825 Mini Launcher includes the following:
• Launcher and Base (Assembled)
• (2) 16mm Steel Balls
• String (to pull trigger)
• Collision Attachment
• Safety Goggles
• Pushrod
• Manual
String
Base
Angle Indicator
Launcher
Trigger
Projectile Balls
Safety Goggles
Collision Attachment
Pushrod
