Dings Dynamics Group 90 Series End Mount NEMA 4 - Manual (Page 3)

Table 1. Parts List
ITEM
NO.
MODEL NUMBER
DESCRIPTION
PART
NUMBER
92125-51 92180-51 93230-51 93270-51 94330-51 94360-51 95450-51 92125-52 92180-52 93230-52 93270-52 94330-52 94360-52 95450-52
QUANTITY
1 1 1 Bracket, 2 disc, NEMA 4 w/ Hub Seal L090162-001
1 1 1 Bracket, 3 disc, NEMA 4 w/ Hub Seal L090163-001
1 1 1 Bracket, 4 disc, NEMA 4 w/ Hub Seal L090164-001
1 1 Bracket, 5 disc, NEMA 4 w/ Hub Seal L090165-001
1 1 1 Bracket, 2 disc, NEMA 4 without Hub Seal L090162-002
1 1 1 Bracket, 3 disc, NEMA 4 without Hub Seal L090163-002
1 1 1 Bracket, 4 disc, NEMA 4 without Hub Seal L090164-002
1 1 Bracket, 5 disc, NEMA 4 without Hub Seal L090165-002
2 4 4 4 4 Stud Post, 2 disc H090131-001
2 4 4 4 4 Stud Post, 3 disc H090131-002
2 4 4 4 4 Stud Post, 4 disc H090131-003
2 4 4 Stud Post, 5 disc H090131-004
3 2 2 3 3 4 4 5 2 2 3 3 4 4 5 Disc, Rotating K090149-001
4 1 1 2 2 3 3 4 1 1 2 2 3 3 4 Disc, Stationary L090173-001
5 2 2 2 2 2 2 2 2 2 2 2 2 2 2 Rod, Manual Release G070001-002
6 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Assembly, Pressure Plate L090171-001
7 4 4 4 4 4 4 4 4 4 4 4 4 4 4 Spring, Torque (Silver) G080002-001
8 4 4 4 4 4 4 4 4 4 4 4 4 4 4 Washer, Torque Spring G090304-001
9 4 4 4 4 4 4 4 4 4 4 4 4 4 4 Nut, Torque Spring W003001-022
10 2 2 2 2 2 2 2 2 2 2 2 2 2 2 Spring, Manual Release Return G060010-001
11 4 4 4 4 4 4 4 4 4 4 4 4 4 4 Nut, Magnet Assemly Locating W003003-023F
12 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Magnet Assembly #
13 4 4 4 4 4 4 4 4 4 4 4 4 4 4 Nut, Magnet Assembly Locking W003013-010
14 AN AN AN AN AN AN AN AN AN AN AN AN AN AN Washer, Manual Release Shim, Thin W004004-004C
15 AN AN AN AN AN AN AN AN AN AN AN AN AN AN Washer, Manual Release Shim, Thick W004004-003C
16 2 2 2 2 2 2 2 2 2 2 2 2 2 2 Lockwasher, Stop Screw W004007-007
17 2 2 2 2 2 2 2 2 2 2 2 2 2 2 Screw, Stop G060029-001
18 1 1 1 1 1 1 1 1 1 1 1 1 1 1 O-ring, cover W006001-037
19 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Cover L090160-001
20 4 4 4 4 4 4 4 4 4 4 4 4 4 4 Washer, sealing W011002-010
21 4 4 4 4 4 4 4 4 4 4 4 4 4 4 Nut, Cover W003001-020
22 2 2 2 2 2 2 2 2 2 2 2 2 2 2 Gasket, Cap G070381-001
23 2 2 2 2 2 2 2 2 2 2 2 2 2 2 Cap, Manual Release G060170-002
24 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Eyebolt, Lifting W032002-003
25 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Nut, Eyebolt Locking W003002-003
26 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Plug, Pipe W010002-002
27 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Clamp, Tube W021003-001
28 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Screw, Tube Clamp W001045-085
29 1 1 1 1 1 1 1 Gasket, Motor Mounting K090134-002
30 1 1 1 1 1 1 1 V-ring, Hub Seal W011008-005
31 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Hub @
32 AN AN AN AN AN AN AN AN AN AN AN AN AN AN Connector, Crimp W022003-001
33 3 3 3 3 3 3 3 3 3 3 3 3 3 3 Leadwire, 18 AWG, Class H W023001-047A
34 AN AN AN AN AN AN AN AN AN AN AN AN AN AN Zip Tie W038001-009A
35 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Nameplate per order
36 2 2 2 2 2 2 2 2 2 2 2 2 2 2 Screw, Drive, Nameplate W001012-048
# = Part number is dependent on voltage and torque of brake - Contact Factory for more information
@ = Part number is dependent on model number and bore size of brake - Contact Factory for more information
AN = As Needed
3
