Dings Dynamics Group 90 Series End Mount NEMA 2 User Manual
Page 3
Table 1. Parts List
ITEM
NO.
92125-50
92180-50
93230-50
93270-50
94330-50
94360-50
95450-50
DESCRIPTION
PART
NUMBER
QUANTITY
1
1
1
Bracket, 2 disc, NEMA 2
L090162-002
1
1
1
Bracket, 3 disc, NEMA 2
L090163-002
1
1
1
Bracket, 4 disc, NEMA 2
L090164-002
1
1
Bracket, 5 disc, NEMA 2
L090165-002
2
4
4
Stud Post, 2 disc
H090131-001
2
4
4
Stud Post, 3 disc
H090131-002
2
4
4
Stud Post, 4 disc
H090131-003
4
Stud Post, 5 disc
H090131-004
3
2
2
3
3
4
4
5
Disc, Rotating
K090149-001
4
1
1
2
2
3
3
4
Disc, Stationary
L090173-001
5
2
2
2
2
2
2
2
Rod, Manual Release
G070001-002
6
1
1
1
1
1
1
1
Assembly, Pressure Plate
L090171-001
7
4
4
4
4
4
4
4
Spring, Torque (Silver)
G080002-001
8
4
4
4
4
4
4
4
Washer, Torque Spring
G090304-001
9
4
4
4
4
4
4
4
Nut, Torque Spring
W003001-022
10
2
2
2
2
2
2
2
Spring, Manual Release Return
G060010-001
11
4
4
4
4
4
4
4
Nut, Magnet Assemly Locating
W003003-023F
12
1
1
1
1
1
1
1
Magnet Assembly
#
13
4
4
4
4
4
4
4
Nut, Magnet Assembly Locking
W003013-010
14
As Needed
As Needed
As Needed
As Needed
As Needed
As Needed
As Needed
Washer, Manual Release Shim, Thin
W004004-004C
15
As Needed
As Needed
As Needed
As Needed
As Needed
As Needed
As Needed
Washer, Manual Release Shim, Thick
W004004-003C
16
2
2
2
2
2
2
2
Lockwasher, Stop Screw
W004007-007
17
2
2
2
2
2
2
2
Screw, Stop
G060029-001
18
1
1
1
1
1
1
1
Cover
L090160-001
19
4
4
4
4
4
4
4
Nut, Cover
W003001-020
20
2
2
2
2
2
2
2
Cap, Manual Release
G060170-002
21
1
1
1
1
1
1
1
Eyebolt, Lifting
W032002-003
22
1
1
1
1
1
1
1
Nut, Eyebolt Locking
W003002-003
23
1
1
1
1
1
1
1
Plug, Pipe
W010002-002
24
As Needed
As Needed
As Needed
As Needed
As Needed
As Needed
As Needed
Connector, Crimp
W022003-001
25
3
3
3
3
3
3
3
Leadwire, 18 AWG, Class H
W023001-047A
26
1
1
1
1
1
1
1
Clamp, Tube
W021003-001
27
1
1
1
1
1
1
1
Screw, Tube Clamp
W001045-085
28
As Needed
As Needed
As Needed
As Needed
As Needed
As Needed
As Needed
Zip Tie
W038001-009A
29
1
1
1
1
1
1
1
Hub
@
30
1
1
1
1
1
1
1
Nameplate
per order
31
2
2
2
2
2
2
Screw, Drive, Nameplate
W001012-048
# = Part number is dependent on voltage and torque of brake -
Contact Factory for more information
@ = Part number is dependent on model configuration of brake -
Contact Factory for more information
Figure 3. Exploded View of Brake
3
