Dings Dynamics Group 60 Series Coupler NEMA 4 User Manual
Page 11

REPLACEMENT
P
A
R
TS LIST
11
*The number of rotating discs is shown in the brake model number
. Example 4-62
006-5153
has two rotating discs.
The number of stabilizing clips is the same as rotating discs.
The
number of stationary discs is one more than the number of rotating discs.
** Part number is determined by one or more of the following: model number
, voltage,
motor shaft diameter and keyway size.
Item
No.
Description
Part Number
Qty
.
25H
Armature plate assembly: includes “I”
through “T” (not shown as an assembly)
H060541-**
1
25I
Armature plate
H060545-003
1
25J
Armature lamination assembly
G060788-002
1
25K
Nyliner bushing
W013005-001
2
25L
Hex. Hd. Capscrew 1/4-20 x 5/8 lg
W001007-002E
2
25M
W
ear adjustment screw sq. hd.
W002003-001
2
25N
Armature spacer
G060798-002
2
25P
Armature shock mount
G060808-003
1
25Q
Locking plate
G060812-001
1
25R
Split spring lockwasher #8
W004006-003
1
25S
Soc. Hd. Capscrew
W001013-201
1
25T
Roll pin 5/32” dia. x 3/8” lg.
W005003-098
1
25U
Locknut 1/4-20
W003013-001
2
26
Hardware bag for 1 & 2 disc models
includes 29 thru 31(not shown)
H060237-1
12
1
27
Hardware bag for 3 disc models includes 29
thru 32 (not shown)
H060237-1
13
1
28
Mounting stud 1 & 2 disc only
W012001-001
4
29
3/8 split spring lockwasher
W004006-008
4
30
Hex nut 3/8-16
W003002-003
4
31
Operating instructions & parts manual
G061031-001
1
32
Mounting stud
W012001-002
4
33
Key 3/16 wq x 1-13/16 lg
W007001-017
1
34
Mounting face gasket
H060344-003
2
35
Double seal ball bearing, 7/8 shaft
W009001-009
1
36
Bearing spacer
G060531-001
1
37
T
ruarc retaining ring, 7/8 shaft
W006007-002
1
38
Pipe plug 1/2”
W001002-004A
1
39
“O” ring, adapter housing, buna-n
W006001-019
1
40
“O’
ring, release rod, buna-n
W006001-025
1
41
Hex hd. Capscrew
, #8-32, SS
W001007-151C
12
42
#8 sealing washer
W01
101
1-002C
12
43
1/8” hex. Soc. pipe plug
W010002-001A
1
44
Key attaching label (not shown)
G060648-001
1
Item
No.
Description
Part Number
Qty
.
1
Bracket 1 &
2
disc
L060256-01
1
1
1
Bracket 3 disc
L060257-01
1
1
2
S
tationary disc
H060147-001
*
3
Compression spring for all except 20 lb-ft
G060821-001
1
3
Compression spring, 20 lb-ft
G060852-001
1
4
Plain brass washer
W004003-024
1
5
Nylon bushing
G060820-001
1
6
Hex nut 5/16-18 thread
W003002-002E
2
7
Adapter housing
L060393-001
1
8
T
wo-piece shaft design
**
1
8A
One-piece shaft design
**
1
9
Cap assembly
, stainless steel
H060658-004
1
10
Splined rotating firction disc
H060157-005
*
11
Hex Hd. Capscrew 1/4-20 x 1/2 lg.
W001008-001E
2
12
Double seal ball bearing 5/8 or 3/4 output shaft
W009001-001
1
13
T
ruarc retaining ring, 5/8 or 3/4 output shaft
W006007-001
1
14
T
ruarc retaining ring, all models
W006002-001
1
15
Release knob
G060848-001
1
16
Release return spring
G060881-001
1
17
Release adjustment screw
W001002-056C
1
18
Release adjustment lock spring
G060795-001
1
19
Pivot stud
W002005-303A
1
20
Nameplate
K060507-001
1
21
Instruction label, 2-piece shaft design
K060492-001
1
21
Instruction label, 1-piece shaft design
K060493-001
1
22
Splined hub for use with item 8
**
1
23
S
tabilizer clip, rotating friction disc (when used)
H060466-001
*
24
W
ire outlet cap plug
W008003-001
1
25
Operator assembly: includes “25A” thru “25U”
K060463-**
1
25A
Magnet assembly
, plated
**
1
25B
Magnet mounting bracet
H060544-001
1
25C
Magnet shock mount
G060813-001
1
25D
Hex. Hd. Capscrew 1/2-20 x 5/8 lb Grade 5
W001007-002E
2
25E
Cable clamp
W021003-001
2
25F
Carriage bolts 1/2-20
G060803-001
2
25G
T
orque spring (blue) 1.5 lb-ft
G060791-001
2
25G
T
orque spring (sliver) 3 & 6 lb-ft
G060792-001
2
25G
T
orque spring (bronze) 10 & 15 lb-ft
G060793-001
2
25G
T
orque spring (green) 20 lb-ft
G060794-001
2
