REPLACEMENT PARTS LIST
Item
No. Description
Std. Housing
6-60000-551 Encl. Housing
4-60000-553 Qty.
Item
No. Description
Std. Housing
6-60000-551 Encl. Housing
4-60000-553 Qty.
1 Bracket 1 & 2 disc L060252 -001 L060256 -001 1 Armature plate assembly: includes “I”
1 Bracket 3 disc L060255 -001 L060257 -001 1
25H
through “T” (not shown as an assem.)
H060541-** 1
2 Stationary disc H060147 -001 * 25I Armature plate H060545-003 1
3 Compression spring for all except 20 lb. ft. G060821 -001 1 25J Armature lamination assembly G060788-001 1
3 Copmression spring, 20 lb. ft. G060852 -001 1 25K Nyliner bushing W013005-001 2
4 Plain brass washer W004003-024 1 25L Hex. Hd. Capscrew 1/4 -20 x 5/8 lg. W001007-002E 2
5 Nylon bushing G060820 -001 1 25M Wear adjustment screw sq. hd. W002003-001 2
6 Hex nut 5/16 -18 thread W003002-002E 2 25N Armature spacer G060798-002 2
7 Adapter housing L060251 -001 1 25P Armature shock mount G060808-003 1
8 Two-piece shaft design ** 1 25Q Locking plate G060812-001 1
8A One-piece shaft design ** 1 25R Split spring lockwasher #8 W004006-003 1
9 Wrap-around cover K060462-001 K060491 -001 1 25S Soc. Hd. Capscrew W001013-201 1
10 Splined rotating friction disc H060157 -005 * 25T Roll pin 5/32” dia. X 3/8” lg. W005003-098 1
11 Hex. Hd. Capscrew 1/4 -20 x 1/2 lg. W001008-001E 2 25U Locknut 1/4 -20 W003013-001 2
12 Double seal ball bearing, 5/8 or 3/4 output shaft W009001-001 1 Hardware bag includes 29 thru 31
13 Truarc retaining ring, 5/8 or 3/4 output shaft W006007-001 1
26
1 & 2 disc mo dels (not shown)
H060237-070 1
14 Truarc retaining ring, all models W006002-001 1 Hardware bag includes 29 thru 32
15 Release knob G060785-001 G060848 -001 1
27
3 disc models (not shown)
H060237-071 1
16 Release return spring G060797-001 G060881 -001 1 28 Mounting stud 1 & 2 disc only W012001-001 4
17 Release adjustment screw W001002-056C 1 29 3/8 split spring lockwasher W004006-008 4
18 Release adjustment lock spring G060795 -001 1 30 Hex nut 3/8 -16 W003002-003 4
19 Pivot stud W002005-303A 1 31 Operating i nstructions & parts manual G060849-001 1
20 Nameplate K060407 -001 1 32 Mounting stud W012001-002 4
21 Instruction label, 2 -piece shaft design K060492 -001 1 33 Key 3/16 sq. x 1 -13/16 lg. W007001-017 1
21 Instruction label, 1 -piece shaft design K060493 -001 1 34 Mounting face gasket H060344 -003 2
22 Splined hub for use with item 8 ** 1 35 Double seal ball bearing,7/8 shaft W009001-009 1
23 Stabilizer clip, rotating friction disc (when used) H060466 -001 * 36 Bearing spacer G060531-001 1
24 Wire outl et cap plug W008003-001 1 37 Truarc retaining ring, 7/8 shaft W006007-002 1
Operator assembly: includes “A” through “U” 38 Pipe plug 1/2” W001002 -004A 1
25
(not shown as assembly)
K060463 -** 1
39 “O” ring adapter, housing to bracket W006001 -019 1
25A Magnet assembly ** 1 40 “O” ring release rod #010 W006001 -025 1
25B Magnet mounting bracket H060544 -001 1 41 Rd. Hd. Screws #10/32 x 1 -1/4 lg. W001002 -082E 2
25C Magnet shock mount G060813 -001 1 42 Locknut #10 -32 W003001 -011F 2
25D Hex. Hd. Capscrew 1/4 -20 x 5/8 lg. Grade 5 W001007-002E 2 43 1/8” hex. Soc. Pipe plug W010002 -001A 1
25E Cable clamp W021003-001 2 44 Key attaching label (not shown) G060648-001 1
25F Carriage bolts 1/4 -20 G060803 -001 2
25G Torque spring (blue) 1.5 lb. f t. G060791 -001 2
25G Torque spring (silver) 3 & 6 lb. ft. G060792 -001 2
25G Torque spring (bronze) 10 & 15 lb. ft. G060793 -001 2
25G Torque spring (green) 20 lb. ft. G060794 -001 2
11
*The number of rotating discs is shown in the brake model number. Example 6-62006-551
has two rotating discs. The number of stabilizing clips is the same as rotating discs. The
number of stationary discs is one more than the number of rotating discs.
** Part number is determined by one or more of the following: model number, voltage,
motor shaft diameter and keyway size.
