Dings Dynamics Group 60 Series End Mount NEMA 2 - Manual (Page 11)

Item
No. Description Part Number Qty.
1 Splined hub K060107-** 1
2 Bracket 1 & 2 disc models (aluminum) L060258-001 1
2 Bracket 3 disc model (aluminum) L060259-001 1
2 Bracket 4 disc model (cast iron) L060285-001 1
3 Release knob G060785-001 1
4 Release return spring G060797-001 1
5 Release adjustment screw W001002-056C 1
6 Release adjustment lock spring G060795-001 1
7 Nameplate K060407-001 1
8 Cap plug W008003-001 1
9 Cover stud G060822-001 2
10 Pivot stud W002005-303A 1
11 Compression spring (all except 20 & 25 lb. ft.) G060821-001 1
11 Compression spring (20 & 25 lb. ft.) G060852-001 1
12 Stationary disc H060147-001 *
13 Splined rotating friction disc H060157-003 *
14 Stabilizer clip, rotating friction disc (when used) H060466-001 *
15 Operator assembly: includes “A” through “T” K060476-** 1
(not shown as an assembly)
15A Magnet assembly ** 1
15B Magnet shock mount G060813-001 1
15C Magnet mounting bracket H060544-001 1
15D Hex hd. capscrew 1/4-20 x 1/2 lg. W001008-001E 2
15E Armature plate assembly: includes “F” through “Q” H060541-** 1
(not shown as an assembly)
Item
No. Description Part Number Qty.
15F Armature plate H060545-003 1
15G Nyliner bushing W013005-001 2
15H Wear adjustment screw, sq. hd. 1/4-20 x 1-1/2” lg. W002003-001 2
15I Roll pin 5/32” dia. x 3/8” lg. W005003-098 1
15J Armature lamination assembly G060788-001 1
15K Armature shock mount G060808-003 1
15L Armature spacer G060798-002 2
15M Hex hd. capscrew 1/4-20 x 5/8” lg. Grade 5 W001007-002E 2
15N Locking plate G060812-001 1
15P Split spring lockwasher #8 W004006-003 1
15Q Soc. hd. capscrew #8-32 x 1/4” lg. W001013-201 1
15R Carriage bolt 1/4-20 G060803-001 2
15S Torque spring (blue) 1.5 lb. ft. G060791-001 2
15S Torque spring (silver) 3 & 6 lb. ft. G060792-001 2
15S Torque spring (bronze) 10 & 15 lb. ft. G060793-001 2
15S Torque spring (green) 20 & 25 lb. ft. G060794-001 2
15T Locknut 1/4-20 W003013-001 2
16 Hex hd. capscrew 1/4-20 x 1/2 lg. W001008-001E 2
17 Nylon bushing G060820-001 1
18 Plain brass washer W004003-024 1
19 Hex nut 5/16-18 W003002-002E 2
20 Cover L060261-002 1
21 Instruction label (not shown) K060496-001 1
22 Locknut 1/4-20 W003001-013 2
23 Release label G060859-001 1
REPLACEMENT PARTS LIST
* Number of rotating discs is shown in the brake model number. Example - 2-62006-524 has two
rotating discs. The number of stationary discs is one more than the number of rotating discs,
with the exception of model 2-64025-524 which has the same number of stationary discs as
rotating discs.
**Part number is determined by one or more of the following: model number, voltage, motor shaft
diameter and keyway size.
11
