SB Wire Sawing System Technical data
SB_0107_e.mif Page 11
:LUH GULYH
+\GUDXOLF GULYH
Hydraulic motors with size 3 connections.
Absorption volumes: 20, 25 and 31 ccm.
&RQQHFWDEOH GULYHV
All types of hydraulic drives with at least one
hydraulic feed can be connected.
We recommend high-performance drives with
a power of at least 20 kW to achieve the
expected cutting capacity of the SB.
+<'52675(66 GULYHV
- CR-3
- CR-5 RC
- DK USA
- AD-S
- AD-S2
- AD-S3
- AD-S4
- AD-S4 RC
- RD
- RD-2
- RD-S
- RD-S RC
:LUH UXQQLQJ GLUHFWLRQ
The running direction of the wire is preset by
the direction of movement of the hydraulic
motor and the design of the drive pulley (free-
running) and cannot be changed.
