Recommended Mounting Heights
Chart 3.1
•
Recommended Mounting Heights*
* Recommended mounting heights are provided as a guideline. Actual conditions may dictate
variations from the above data. Clearance to combustibles must always be maintained.
The recommended mounting heights of the units are critical to its performance. Refer to the Chart 3.1
for specific recommended mounting heights. The mounting height is measured from the finished floor to
the bottom of the unit. Units that are mounted higher than the recommended mounting heights may not
directly deliver heated air to the floor level.
3.0
Installation
•
Recommended Mounting Heights
Model
Typical
Mounting Height
Approximate
Heat Throw
Average Air
Temperature Rise
FA-100
12 to 14 ft.
43 ft.
50°F
FA-125
14 to 16 ft.
57 ft.
50°F
FA-150
14 to 16 ft.
52 ft.
50°F
FA-175
15 to 17 ft.
51 ft.
50°F
FA-200
15 to 17 ft.
55 ft.
50°F
FA-225
16 to 18 ft.
59 ft.
50°F
FA-250
16 to 18 ft.
63 ft.
50°F
