Max Machinery, Inc.

240 Series User Manual

© Copyright 2013

Rev. 002Q4

6

Meter Specifications

Model

241

242

243

1

Maximum flow rate,

Gal/min

50

140

370

Liters/min

189

540

1400

Maximum pressure, bar (psi)

Standard NPT

35, (500)

35, (500)

35, (500)

600 lb ANSI RF flanges

105 (1500)

105 (1500)

105 (1500)

1500 lb ANSI RF flanges

---

245 (3500)

245 (3500)

2500 lb ANSI RF flanges

245 (3500)

---

---

Pressure drop, bar (PSI)

Operating maximum

10 (150)

7 (100)

5.3 (75)

Absolute maximum

21 (300)

15 (200)

10 (150)

100% flow, 3 CPS

1 (14)

0.7 (10)

0.7 (10)

2

Maximum temperature

Up to 265° C (500° F)

3

Recommended filtration

150 micron

Displacement, L/Rev

0.062

0.182

0.574

Weight, Kg (Lb)

13.6 (30)

18.2 (40)

45.5 (100)

4

Typical K-Factor, (pulses/liter)

295 Transmitter

15000

5000

1500

289-700 Transmitter

403

219

58.8

Port size

NPT

1.5”

2.5”

3”

ANSI RF flanges

1.5” (DN40)

2.5” (DN65)

4” (DN100)

Notes:

1

For viscosities of 3 CPS or less. Derate per pressure drop curves for higher viscosites.

2

Limited by meter seal material, transmitter model, orientation and ambient temp. See manual. Consult factory.

3

Some materials may have different filter requirements. Consult factory

4

Typical. See flow meter/transmitter calibration sheet for actual K-factor and accuracy data.
