Max Machinery, Inc.

240 Series User Manual

© Copyright 2013

Rev. 002Q4

14

Analog

294 NPT model

All Other Models

Mating Cable

Wire Color

Turck

Pin #

Case Ground

In-lid

Case

Blue

3

Common

1

Com

Black

4

Power *

2

V+

Brown

1

Signal Output (+)

3

Sig

Grey

5

Signal Output (-)**

4

Ret

White

2

WARNING

Installation and removal should only be facilitated by trained personnel
Verify transmitter output type (ANALOG or FREQUENCY) before wiring, inappropriate wiring could
result in damaging the circuit.

Removal note: The transmitter does not need to be removed from the flow meter for any field servicing or adjustments.
Normally, the flow meter and transmitter are shipped back to the factory for calibration or service as a unit. If the
transmitter needs to be removed from the flow meter for installation, be sure to retighten the transmitter snugly in
order to ensure proper sensor alignment.

Mechanical Installation
1. The transmitter is attached to the flow meter’s threaded magnet shield. Hand tighten only. (~ 3 ft-lb)
2. The transmitter lid has four thread paths. To realign the cable, remove the lid and rotate up to 180° and retighten
using an alternate starting point. Tighten to compress the O-ring seal.

Removal
1. Remove electrical connections
2. Unscrew transmitter, using a wrench if necessary.

Moisture Seal Protection
On all models, the housing is designed as a liquid and vapor-tight enclosure. There are O—ring seals at the lid and
possibly also the base of the housing — these need to be fully seated. A properly sealed transmitter will prevent the
formation of damaging moisture inside the housing.
Turck connector Model: The connector is sealed to the lid at the factory and is ready for use.
NPT Model: To ensure a moisture-tight seal, apply appropriate sealant to the threads at installation.

Wiring ANALOG

The electrical connector versions are pre-wired inside the transmitter and ready to accept a mating cable (available from
the factory). The liquid-tight, NPT models need to be wired during installation as shown in the table below:

*Model 29X-xxx-000, 24vdc powered, Model 29X-xxx-100, 12vdc powered
** Signal output is fully isolated: If attached to a true differential input a 10K Ohm pulldown resistor
should be installed between (—) and common at the receiving end.

Electrical Installation - Wiring

290 Series Transmitters
