Before You Install
Thank you for choosing to install a Max Machinery precision flow meter. To ensure the best experience please take a
moment to read through this manual prior to installation.
When you purchased this meter a flow engineer helped determine many of the factors that will be reviewed on the
following pages. You may find it useful to fill out the form below and keep it in your files for reference.
When you are ready to do the installation there will be a few tools you will need:
Meter Installation:
The meter and transmitter
A signal cable (available from factory)
The display or signal processing device
Indicator Manual
Calibration Certificate
Bypass plumbing supplies
Many Max meters are installed and operate for decades, so having the following information in your records may prove
useful. We have provided this outline as a starting point.
Process Temperatures ___________________________
Fluid Viscosity ____________________________________
Operating Range ________________________________
Line Pressure ____________________________________
Max Sales # or PO # _____________________________
Installation Date __________________________________
Meter Model # __________________________________
Meter Serial # ____________________________________
Transmitter Model # _____________________________
Transmitter Serial # _______________________________
Notes: _____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
_____________________________________________________________________________________________
