Magnum Venus Plastech UPMS-1000 Monitoring System User Manual
Page 25
OPERATIONS MANUAL
UPMS-1000-XXX
MAGNUM VENUS PLASTECH
REV 1.02
NOVEMBER 2010
PAGE 25
10. Cycle display using the MODE button, until the
RATE B
is displayed.
11. Press and hold the ENT button until the display enters program mode. At this point you should
see
KFR B VALUE
, with a number underneath it. The first digit should be blinking.
12. Using the UP or DN and SEL buttons adjust the
KFR B VALUE
to figures calculated from
above.
13. Press ENT
to accept
KFR B VALUE
setting. This will then move to the next screen.
14. Press ENT
to accept
SAMPLE B
setting.
15. Note: Do not adjust the SAMPLE A SETTING!
16. Press ENT
to accept
ENG UNITS B
setting.
17. Note: Do not adjust the SAMPLE A SETTING!
18. Calibration for
RATE B
is now complete.
After this is complete, a test sample should be dispensed into a cup and timed while noting the reading on
the display. If the desired result is not achieved it is possible to adjust the KFR factor in small increments
to match the output of the dispensing unit.
