Chapter 2-overview, Descrption, Items and tools needed – Magnum Venus Plastech UPMS-1000 Monitoring System User Manual
Page 15
OPERATIONS MANUAL
UPMS-1000-XXX
MAGNUM VENUS PLASTECH
REV 1.02
NOVEMBER 2010
PAGE 15
CHAPTER 2-Overview
DESCRPTION
The UPMS-1000 Monitoring System can be used wherever 2 components are being dispensed. The
UPMS-1000 will monitor both components individually and report back ratios, flow rates, and material
totals.
Using high precision, straight or helical gear flow transmitters, insures that each component is being
monitored precisely. Each meter will feedback to a small PLC which when properly calibrated will report
corresponding ratios, flow rates and totals.
Each flow meter is machined with high precision, utilizes high quality Teflon seals and when sized
properly will not impede flow rates.
ITEMS AND TOOLS NEEDED
.
Scale capable of display weight increments to .01 lbs and will weigh up to 5 lbs.
Plastic or paper quart cups.
Calculator.
Set of Allen keys.
6” Adjustable wrench.
Ratio block assembly for MVP Pro Series mixing head.
