Display readouts – Magnum Venus Plastech UPMS-1000 Monitoring System User Manual
Page 21
OPERATIONS MANUAL
UPMS-1000-XXX
MAGNUM VENUS PLASTECH
REV 1.02
NOVEMBER 2010
PAGE 21
DISPLAY READOUTS
RATIO A B
Monitors the ratio of component A to component B
TOTAL A B
Displays the individual totals of components A and B dispensed
STATUS ONE
Maintenance display to check for flow meter pickup operation and erratic counts
WARNINGS
Shows the values at which the alarms are set for the RATIO A B
RATE A
Displays A component flow rate
RATE B
Displays B component flow rate
TOTAL A
Displays the total of component A dispensed
TOTAL B
Displays the total of component B dispensed
