H.I.S. Troubleshooting Manual
SHOULD THE EYES OR INTERNAL
PARTS OF THE BODY COME IN
CONTACT WITH MEKP, A
PHYSICIAN SHOULD BE
CONTACTED IMMEDIATELY.
CHAPTER 3
Note: parts of catalyst system should always be cleaned with clean water only.
Catalyst pump:
Problem
Cause
Action
No cure catalyst
pump
No catalyst. Supply
below outlet fitting on
catalyst jug.
Replenish supply.
No cure, catalyst
pump not
delivering
Quick pin in slave
arm not fixed to
catalyst pump.
Install Quick Pin.
Catalyst Pump
failure*
A. Piston Seal
Failure
Remove catalyst hose, catalyst feed tube
and relief valve tube from catalyst pump.
Remove pump from slave arms. Loosen
locknut on pump cylinder and unscrew
cylinder from outlet body. Slide cylinder
down from piston rod and piston assembly.
Remove seal retainer and remove and
replace piston seal. Be sure spring in
piston seal faces the top of the pump.
Remove O-ring from inside of outlet body
and place on end of cylinder above lock
nut. Reassemble unit.
