Appendix A:
Display Programming:
OPERATING MODE DISPLAY DESIGNATORS
“R” - To the left of the display is the rate value.
- Counter A has no designator.
Pressing the SEL button toggles the meter through the selected displays. If display
scroll is enabled, the display will toggle automatically every four seconds between the
rate and count values.
KEY DISPLAY MODE OPERATION ENTERING PROGRAM MODE PROGRAMMING MODE OPERATION
SEL Index display through enabled values Press and hold for 2 seconds to activate Store selected parameter and index to next parameter
RST Resets count display(s) and/or outputs Advances through the program menu/
Increments selected parameter value or selection
The Resin Rate can be calculated by:
If the number of counts /
pulses per “single” unit (i.e. # of counts (pulses) per pound) is
known, then it can be entered as the Scaling Input value and the Scaling Display value
will be entered as the following:
RATE PER DISPLAY (RAtE dSP)
INPUT (RAtE INP)
Second 1 # of pulses per unit
Minute 60 # of pulses per unit
Hour 3600 # of pulses per unit
Notes:
1. The decimal place can be adjusted by multiplying the values by 10 or 100, both
values must be raised and lower by the same proportion i.e. if the display value is
raised by a multiple of 10 then the input value must be raised by the same.
2. Both values must be greater than zero (0).
3. If # of pulse per unit is less than 1, then multiply both Input and Display values by
100.
4. If # of pulse per unit is less than 10, then multiply both Input and Display values
by 10.
Procedures for determining the number counts per unit:
Items needed: Accurate Scale
– capable of weighing 5 – 10 lbs (2.5 – 5 kg)
Appropriate size container
