Metering pump manual – Magnum Venus Plastech HYDRAULIC MINI LINK User Manual
Page 30
Mini Link Operations Manual
Rev. 08/2013
Page | 30
Metering Pump Manual:
The Mini Link comes standard with two VHPC-2200 Metering Pumps a 1:1 to 3.7:1
ratio. It can also be used in combination with the VHPC-3200 Metering Pump for 1.84:1
to 5.85:1 or VHPC-4200 Metering Pump for 4.15:1 to 13:1 ratios.
Depending on the metering pump combination installed on this unit you will see one or
two of the following manuals:
See Manual “VHPC-1200 Metering Pump Manual”
See Manual “VHPC-2200 Metering Pump Manual”
See Manual “VHPC-3200 Metering Pump Manual”
See Manual “VHPC-4200 Metering Pump Manual”
