operatIon
cIM100 run Mode
The.CIM100.user.interface.consists.of.two.modes,.the.run.mode,.which.is.for.everyday.metering,.and.the.menu.mode,.
which.is.for.setup,.calibration,.and.diagnostics..In.run.mode,.the.CIM100.display.shows.a.running.totalizer,.the.unit.of.
measurement,.and.any.active.indicator.lights..
Run.mode.is.active.only.when.the.Chassis.Intrusion.button.is.held.down..In.normal.operation,.the.CIM100.cover,.
fastened.flush.to.the.housing,.holds.the.Chassis.Intrusion.button.down..
Magnetic switches
The.CIM100.has.two.magnetic.switches.that.can.be.toggled,.while.the.cover.is.on,.by.passing.a.magnet.over.the.
switch.location..
One.magnetic.switch,.located.above.the.display,.toggles.the.display.between.the.grand.totalizer.and.a.resettable.
totalizer..The.other.magnetic.switch,.located.to.the.left.of.the.display,.sets.the.resettable.totalizer.to.zero..
cIM100 chassis Intrusion
If.the.CIM100.cover.is.removed,.the.electronics.will.immediately.enter.the.chassis.intrusion.error.state..The.display.will.
flash.“violated”,.all.internal.controls.will.lock.(if.a.password.is.set),.and.the.meter.will.not.register.any.product.passing.
through.the.meter..To.return.the.meter.to.working.condition,.see. Run Mode Violation and Reset Chassis Intrusion.
in.the.Menu.Mode.Options.on.page.12.
CIM100
FLOW RANGES
5-50 GPM
19-190 LPM
.019-.190 M 3
Sponsler Precision Turbine Flowmeters
A Unit of IDEX Corporation
105 Albrecht Dr. Lake Bluff, IL 60044
1.847.295.1050 www.liquidcontrolsgroup.com
LIQUID CONTROLS
Resettable Totalizer/Grand Totalizer
Magnetic Toggle Switch
Resettable Totalizer
Magnetic Reset Switch
LIT
