- - 22 -
. = Decimal point (optional).
A = Alarm Character (optional). A = no alarms, B = alarm 1 active, C = alarm 2 active, D
= alarms 1 & 2 active.
= Carriage return character
Remote S Data Format: SDDDDDD.A
S = Sign of value (optional), space (or +) for positive, - for negative value.
D = Data. Number of digits can be 1-6.
. = Decimal point (optional).
A = Alarm Character (optional). A = no alarms, B = alarm 1 active, C = alarm 2 active, D
= alarms 1 & 2 active.
= Carriage return character
Remote C Data Format: STXXXSDDDDDD.SP
ST = Start character
XXX = Data to be ignored (Skip No.)
S
= Sign of value (optional), space (or +) for positive, - for negative value.
D = Data. Number of digits can be 1-6 (Show No.)
. = Decimal point (optional).
SP = Stop character
CHAR 2 - Address Codes for Remote A
A Serial Communications Address Code from 1 to V follows the “*” to indicate the device
address number from 1 to 31.
Device #
Address
Code
Device #
Address
Code
Device #
Address
Code
1
2
3
4
5
6
7
8
9
10
11
1
2
3
4
5
6
7
8
9
A
B
12
13
14
15
16
17
18
19
20
21
22 C
D
E
F
G
H
I
J
K
L
M
23
24
25
26
27
28
29
30
31 N
O
P
Q
R
S
T
U
V
