©2010 Cypress Computer Systems, Inc. 2/1/10 WDG-5912 Programming Instructions Version 1.0.2 Page 19
Programming the Cypress 5912 programmable wedge using the Cypress Website utility
1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0
P0 1 1 0 1AAAAA AAAAAXXX XXXXXX XXXX XXXXXXXP
Badge
Start
Badge Length = 20bits
Badge Start = 17 (17 bits starting from left side)
Badge Len = 20
17 bits
1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0
P0 1 1 0 1AAAAA AAAAAXXX XXXXXX XXXX XXXXXXXP
Facility
Code Start
FC Length =
10bits
FC Start = 7 (7 bits starting from left side)
FC Len = 10
7 bits
FC output = 5
Badge Output = 7
In this example the FC is 10 bits long, which yields a
maximum
decimal value of 1024. 5 digits is the default setting and is
large enough to hold this value.
The Badge number is 20 bits long, which yields a maximum
decimal value of 1048576. 7 digits are necessary to hold
this value.
Determining Badge Number Parameters
Determining Facility Code Parameters
Determining Output Simulator Parameters
