©2010 Cypress Computer Systems, Inc. 2/1/10 WDG-5912 Programming Instructions Version 1.0.2 Page 11
\R
======== Reader Parameters =======
073 Interface:
00
074 Format: 00
075
24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44
00 00 01 00 00 00 00 00 00 00 00 01 00 00 00 00 00 00 00 00 00
45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0C5 User 0 WPP: 000000000000
0CB + Offset 0: 0000 0CD - Offset 0: 0000
0DC User 1 WPP: 0000000000
0E1 Odd Mask 1: 000000000000000000 0EA Even Mask 1: 000000000000000000
0F3 ABA Clock Polarity: 00
0F4 ABA PAN (Strt,Num): 00,00
0F6 ABA XAN (Strt,Num): 00,00
073 Interface: 00
074 Format: 00
073 is the address of the Interface Parameter. It indicates the
type of reader connected to the wedge.
00 = Wiegand, 01= Strobed.
The Format Parameter is also used to specify the type of
reader. 00 = Binary, 01 = ABA encoding
To change the Interface and format parameters, use the following examples:
\L0107300 - Wiegand Interface
\L0107301 - Strobed Interface
\L0107400 - Binary Formats (24 to 103 bits)
\L0107401 - ABA Formats
Since the 2 fields are sequential in memory, the following example shows both
parameters being set with one command string:
\L020730001 - Wiegand Interface with ABA Encoding
Commands
A similar screen will appear when connected to a VT-220
type terminal
WDG-5912 Programming - The Reader interface Screen
