Fig. 20
1
2
To release the operator, remove the plastic cover, insert the key
and turn the release lock counter-clockwise for about one turn.
(Fig. 22 ref. 1)
To lock the operator again, turn the release lock clockwise until
reaching the stop point, do not force (Fig. 22 ref. 2)
Fig. 22
1
2
4.2.3 USING THE RELEASE SYSTEM
1
Fig.21
The presence of air in the hydraulic circuit causes the automated
system to operate incorrectly, i.e. a faulty movement of the leaf
and too much noise while operating. Please refer to the procedure
illustrated in paragraph 4.2.2 to correct this problem:
THE S800H OPERATOR IS SUPPLIED WITH THE
HYDRAULIC CIRCUIT ALREADY AIR FREE. DO NOT
BLEED. BLEEDING IS ONLY NECESSARY IN THE
EVENT OF MAINTENANCE OF THE HYDRAULIC
SYSTEM, OR INSTALLATION OF THE HYDRAULIC
MANUAL RELEASE
Run a functional check of the system at least every 6 months,
with special attention to the efficiency of the safety and release
devices (including the thrust force of the operator), and to the
smooth operation of the gate hinges.
5. MAINTENANCE
5.1 BLEEDING OPERATIONS
13 FAAC Model S800H Swing Gate Operator
