NOTE : In order to c om ply wi th UL 325, two s ets
of FA A C photobeams m us t be ins talled. One s et
s hould be 6 in. outs ide the c los ed gate(s ) and ac t
as a c l os ing rev ers ing dev ic e. A nother s et s hould
be 6 in. bey ond the s wi ng of the gate(s ) and ac t
as an openi ng rev ers ing dev ic e. The ins taller i s
res pons ible for determ ining the appropri ate
m ounti ng height.
22 23 24 25
1 2 3 4 5 6 7 8
N L
9 10 11 12 13 14 15 16 17 18 19
115 V A C +/- 10%
or
230 V A C +6/ -10%
50-60 Hz
20 21
-
S TOP OP E N OP E N
(1 of 2)
24V
+
FS W
OP C L -
FS W
- - +
W .LIGH T
24 vdc
3 W
LOCK
E LE C TRIC LOCK
1
2
1
2
3
4
5
1
2
3
4
5
1
2
FS W OP
FS W CL
Other safeties
LA MP
BL
U
E
MOTOR 1
C 1
M1
OP C OM C L
BL
U
E
MOTOR 2
C 2
M2
OP C OM C L
Page 16
December, 2003
422 Operator And
455 D Control Panel Installation Manual
Figure 11.
The terminal strip wiring of the
455 D with photobeams
You cannot check the motor’s direction of rotation
without these circuits (jumpers) or the accessories.
When properly prepared for testing, the LEDS FSWOP,
STOP, and FSWCL should be illuminated (see figure 13
on page 17).
WARNING! Running the operator—even for
testing purposes—without a connected reversing
device is potentially dangerous. Do not place
yourself within the path of the moving gate
during your test.
Disengage the operator(s) with the Manual Release
key (see operator installation manual), and open the
gate by hand about halfway.
Next, engage the operator(s) with the Manual Release
key so that you can check the rotation of the motor
(s).
To activate the operator(s) momentarily short across
terminals 9 and 14.
Turn on the main power and send an activating signal
to the operator. The gate leaf (or leaves) should open.
If a gate leaf closes, then you need to turn off the
main power and reverse the connection of the red
and black wires on terminal block J4 for the operator
controlling that leaf. Then you need to recheck the
rotation direction again.
After having completed your test of the motor’s
direction of rotation, replace any test circuits you
installed (between terminals 11 and 16, between 12
and 19, and between 13 and 19) with the proper
reversing and stop devices. The instructions for
installing such accessories follow.
C
ONNECT
O
THER
D
EVICES
WARNING! Turn the main power off before you
make any electrical connections.
P OWER S UPPLY FOR A CCESSORIES : You can access a 24
VDC output for supplying power to accessories
through terminals 17 or 18, (+) and 14 or 15 or 16, (-)
on terminal block J1. In most cases, this source can be
used to power 24 VDC accessories.
N OTE : The 455 D control panel allows a
maximum accessory load of 800 mA.
R EVERSING D EVICES : Reversing devices include
photocells, inductive loops, and so forth. All of the
reversing devices should have contacts of the normally
closed (N.C.) type. Where you connect a device
depends on whether you want the device to operate
during opening or during closing.
N OTE : UL does not recognize the FAAC system
with loop detectors or safety edges. FAAC
photobeams must be used to comply with UL 325.
To wire photobeams, refer to page 19 (see FSWOP for
opening photobeams, and FSWCL for closing
photobeams). Photobeams must be connected as
shown. See also page 19 for the wiring of inductive
loops. If using more than one reversing device, they
must be wired in series.
T
HE
455 D C
ONT
R
OL
P
ANE
L
I
NSTALLA
T
ION
I
NS
TRUCTIONS
