CSB Battery XTV12850 User Manual
12v 85ah, Powered by

6
12
85 Ah @
Approx. 31.2 kg(68.78 lbs)
800A(5sec)
Approx. 4.2mΩ
13.5 to 13.8 VDC/unit Average at
25.5A
14.4 to 15.0 VDC/unit Average at
CSB Batteries can be stored for more than 6 months at
25°C(77°F). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
Discharge:
Charge:
Storage:
I2-Thread lead alloy recessed terminal to accept M6/M8 bolt
PP (UL 94-HB) & Flammability resistance
of (UL 94-V0) can be available upon request.
Cells Per Unit
Voltage Per Unit
Capacity
Weight
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
Nominal Operating Temperature Range
Float Charging Voltage
Recommended Maximum Charging
Current Limit
Equalization and Cycle Service
Self Discharge
Terminal
Container Material
XTV 12850 is a general battery up to 12 years expected life in
standby service or more than 260 cycles at 100% discharge in
cycle service . XTV has a wider operating temperature range,
which makes them more suitable for the systems in harsh
conditions.
Constant Current Discharge Characteristics Unit:A (25°,77°F)
XTV12850
12V 85Ah
Specification
Powered by
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
217.3±2.5 (8.56±0.10)
213.9±2.5 (8.42±0.10)
343.0±2.5 (13.50±0.10) 170.0±2.0 (6.69±0.08)
10hr-rate to 1.80V per cell
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
Constant Power Discharge Characteristics Unit:W (25°,77°F)
@25°C (77°F)
25°C (77°F)
25°C (77°F)
-20°C~50°C (-4°F~122°F)
-20°C~50°C (-4°F~122°F)
-15°C~40°C (5°F~104°F)
F.V/Time
5MIN
10MIN
15MIN
30MIN
60MIN
90MIN
2HR
3HR
5HR
8HR
10HR
20HR
1.60V
323
224
170
103
62.0
45.7
36.8
25.3
16.1
10.7
8.90
4.64
1.67V
286
209
163
101
60.6
44.7
36.0
25.1
15.9
10.6
8.80
4.61
1.70V
266
200
159
99.4
59.9
44.3
35.7
24.8
15.8
10.5
8.78
4.59
1.75V
236
185
151
95.6
58.3
43.0
34.6
24.1
15.6
10.3
8.58
4.54
1.80V
215
166
139
90.1
56.1
41.3
33.2
23.6
15.3
10.2
8.50
4.46
1.85V
178
148
121
82.7
52.3
38.5
31.0
22.4
14.5
9.85
8.10
4.28
F.V/Time
5MIN
10MIN
15MIN
30MIN
60MIN
90MIN
2HR
3HR
5HR
8HR
10HR
20HR
1.60V
3027
2260
1819
1125
687
507
409
290
187
125
104
54.3
1.67V
2800
2148
1765
1113
678
501
404
287
185
124
103
53.7
1.70V
2704
2085
1745
1102
676
498
401
285
183
123
102
53.4
1.75V
2536
1956
1636
1068
662
487
391
278
182
122
101
53.2
1.80V
2234
1816
1499
1017
638
468
376
272
178
120
100
52.4
1.85V
1901
1615
1320
945
601
442
356
259
169
116
96.6
50.8
25°C±3°C (77°F±5°F)
RA1403
Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
