CSB Battery EVH12390 User Manual
12v 39ah, Powered by
Cells Per Unit
6
Voltage Per Unit
12
Capacity
39Ah @ 20hr-rate to 1.75V per cell @25 (77 )
Weight
Approx. 11.5 kg (25.35 lbs)
Maximum Discharge Current
400A(5sec)
Internal Resistance
Approx. 8 m
Operating Temperature Range
Nominal Operating Temperature Range
25
3 (77
5 )
Float Charging Voltage
13.5 to 13.8 VDC/unit Average at 25 (77 )
Recommended Maximum Charging
11.7A
Current Limit
Equalization and Cycle Service
14.4 to 15.0 VDC/unit Average at 25 (77 )
Self Discharge
CSB Batteries can be stored for more than 6 months at
25 (77 ). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
Terminal
B5-L terminal to accept M6 nut & bolt
Container Material
ABS(UL 94-HB) & Flammability resistance of
(UL 94-V0) can be available upon request.
Discharge: -15 ~50 ( 5 ~122 )
Charge: -15 ~40 ( 5 ~104 )
Storage: -15 ~40 ( 5 ~104 )
Constant Power Discharge Characteristics Unit:W (25
,77 )
Constant Current Discharge Characteristics Unit:A (25
,77 )
EVH 12390
12V 39Ah
Specification
Powered by
EVH 12390 is designed specially for electric vehicles,
such as electric golf cart, electric wheelchair, mower,
dust collector...etc. It has high cycling life, high
efficiency and long service life.
F.V/Time
30MIN
60MIN
90MIN
2HR
3HR
4HR
5HR
8HR
10HR
20HR
1.60V
39.6
23.3
17.8
14.4
10.4
8.25
6.93
4.68
3.89
2.13
1.67V
38.5
22.9
17.5
14.2
10.3
8.19
6.87
4.60
3.81
2.06
1.70V
37.4
22.4
17.2
14.0
10.2
8.13
6.79
4.53
3.73
2.01
1.75V
36.4
22.0
16.8
13.7
10.1
8.04
6.71
4.46
3.67
1.96
1.80V
35.4
21.6
16.6
13.5
9.93
7.94
6.62
4.40
3.60
1.91
1.85V
34.3
21.1
16.2
13.3
9.78
7.80
6.52
4.33
3.54
1.87
F.V/Time
30MIN
60MIN
90MIN
2HR
3HR
4HR
5HR
8HR
10HR
20HR
1.60V
475
280
213
172
124
99.0
83.2
56.2
46.6
25.5
1.67V
463
276
210
170
123
98.1
82.4
55.3
45.6
24.8
1.70V
451
271
207
168
122
97.2
81.5
54.4
44.8
24.1
1.75V
438
265
204
166
120
96.2
80.5
53.6
44.0
23.5
1.80V
425
260
201
163
119
95.0
79.4
52.8
43.3
22.9
1.85V
412
253
197
160
117
93.7
78.2
52.0
42.6
22.4
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
178.3±2.0 (7.02 ±0.08)
154.8±2.0 (6.09±0.08)
195.6±2.0 (7.70±0.08) 130.0±1.5 (5.12±0.06)
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
(http://www.csb-battery.com)
by TUV CERT according to ISO 9001,ISO 14001.
The system of manufacturer was certified
RA1308
Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
