CSB Battery XHRL12360W User Manual
Powered by

XHRL 12360W is specially designed for high efficient
discharge and long life application. Its characteristics are
high energy density , small footprint and high discharge
efficiency. It can be used for more than 260 cycles at 100%
discharge in cycle service, up to10 years in standby service.
Cells per unit
Voltage per unit
Capacity
Weight
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
Nominal Operating Temperature Range
Float Charging Voltage
Recommended Maximum Charging
Current Limit
Equalization and Cycle Service
Self Discharge
Terminal
Container Material
6
12
360W @15 min-rate to 1.67V per cell @25
(77 )
Approx. 27.5 kg (60.63 lbs)
800A(5sec)
Approx. 4m
25
3
(77
5 )
13.5 to 13.8 VDC/unit Average at 25
(77 )
36 A
14.4 to 15.0 VDC/unit Average at 25
(77 )
CSB Batteries can be stored for more than 6 months at
25 (77 ). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
I2-Thread lead alloy recessed terminal to accept M6/M8 bolt
Polypropylene(UL 94-HB) & Flammability resistance
of (UL 94-V0) can be available upon request.
Discharge: -20 ~50
(-4 ~122 )
Charge: -20 ~50
(-4 ~122 )
Storage: -15 ~40
(5
~104 )
Constant Power Discharge Characteristics Unit:W (25
,77 )
Constant Current Discharge Characteristics Unit:A (25
,77 )
XHRL12360W
12V 360W
Specification
Powered by
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
214.2±2.5 (8.43±0.10)
211.2±2.5 (8.31±0.10)
261.0±2.5 (10.28±0.10) 168.5±2 (6.64±0.08)
F.V/Time
2MIN
4MIN
6MIN
8MIN
10MIN
15MIN
20MIN
30MIN
60MIN
90MIN
1.60V
468
383
319
273
239
182
145
104
57.3
40.4
1.67V
405
352
300
257
228
176
142
102
56.9
40.3
1.70V
373
324
290
252
221
173
139
101
56.5
40.1
1.75V
347
299
267
234
210
165
133
98.4
55.4
39.4
1.80V
319
284
244
214
194
152
125
92.8
54.0
38.5
1.85V
281
238
208
192
174
139
115
86.9
50.3
34.7
F.V/Time
2MIN
4MIN
6MIN
8MIN
10MIN
15MIN
20MIN
30MIN
60MIN
90MIN
1.60V
4,544
3,982
3,529
3,081
2,758
2,198
1,735
1,232
678
485
1.67V
4,125
3,665
3,339
2,956
2,646
2,160
1,711
1,209
676
480
1.70V
3,850
3,516
3,203
2,830
2,530
2,080
1,664
1,184
668
477
1.75V
3,593
3,327
3,073
2,677
2,400
1,986
1,597
1,160
658
468
1.80V
3,376
3,020
2,777
2,476
2,240
1,858
1,514
1,102
644
459
1.85V
2,750
2,571
2,436
2,232
2,016
1,686
1,365
1,029
598
434
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
RA1308
Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
