CSB Battery UPS123607 User Manual
Powered by

Cells Per Unit
6
Voltage Per Unit
12
Capacity
360W @ 5min-rate to Watt(1.60V)/pcs @25°C (77°F)
Weight
Approx. 2.00 kg(4.41 lbs)
Maximum Discharge Current
100/130A(5sec)
Internal Resistance
Approx. 22mΩ
Operating Temperature Range
Nominal Operating Temperature Range
Float Charging Voltage
13.5 to 13.8 VDC/unit Average at
Recommended Maximum Charging
3.0A
Current Limit
Equalization and Cycle Service
14.4 to 15.0 VDC/unit Average at
Self Discharge
CSB Batteries can be stored for more than 6 months at
Please charge batteries before using. For
higher temperatures the time interval will be shorter.
Terminal
Container Material
Discharge:
Charge:
Storage:
F1/F2-Faston Tab 187/250
ABS(UL 94-HB) & Flammability resistance of
(UL 94-V0) can be available upon request.
Constant Power Discharge Characteristics Unit:W (25°C,77°F)
Constant Current Discharge Characteristics Unit:A (25°C,77°F)
UPS12360 7
Specification
Powered by
UPS 123607 is specially designed for high efficient discharge
application. Its characteristics are high energy density, small
footprint and high discharge efficiency. It can be used for more
than 260 cycles at 100% discharge in cycle service, up to 5 years
in standby service.
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
98.3±1.0 (3.87±0.04)
94.0±1.0 (3.7±0.04)
151.0±2.0 (5.94±0.08)
65.0±1.0 (2.56±0.04)
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
F.V/Time 2MIN
3MIN
4MIN
5MIN
6MIN
7MIN
8MIN
10MIN
15MIN
20MIN
30MIN
60MIN
90MIN
1.60V
62.8
49.5
41.5
35.5
30.8
27.3
24.5
20.5
14.9
11.9
8.71
5.04
3.61
1.67V
55.7
46.1
39.2
34.0
29.7
26.5
24.0
20.2
14.8
11.8
8.66
5.02
3.60
1.70V
52.2
44.5
38.1
32.9
29.0
25.9
23.5
19.9
14.6
11.7
8.63
4.98
3.57
1.75V
47.1
40.8
35.0
30.7
27.2
24.3
22.4
19.1
14.3
11.5
8.50
4.95
3.56
1.80V
42.0
36.4
31.5
27.9
24.8
22.5
20.7
17.9
13.6
11.1
8.30
4.86
3.51
1.85V
36.6
31.1
27.2
24.2
21.9
20.1
18.5
16.3
12.6
10.4
7.83
4.64
3.36
F.V/Time 2MIN
3MIN
4MIN
5MIN
6MIN
7MIN
8MIN
10MIN
15MIN
20MIN
30MIN
60MIN
90MIN
1.60V
550
468
405
360
322
291
268
228
170
137
100.0
58.6
43.0
1.67V
522
447
390
352
315
285
263
225
169
136
99.7
58.4
42.5
1.70V
499
435
383
344
309
281
258
222
167
134
98.4
58.2
42.2
1.75V
462
407
365
326
295
270
249
214
164
132
96.8
57.8
41.9
1.80V
428
376
339
301
274
252
232
203
156
128
95.2
56.3
41.4
1.85V
374
339
298
272
248
228
211
186
144
120
91.6
54.2
39.8
25°C (77°F)
25°C (77°F)
25°C (77°F).
-15°C~50°C ( 5°F~122°F)
-15°C~40°C ( 5°F~104°F)
-15°C~40°C ( 5°F~104°F)
25°C±3°C (77°F±5°F)
(http://www.csb-battery.com)
by TUV CERT according to ISO 9001,ISO 14001.
The system of manufacturer was certified
RA1308
Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
