CSB Battery MSV1000 User Manual
Msv 1000, Powered by

is a long service life battery up to 15
Constant Power Discharge Characteristics Unit:W (25
,77 )
Constant Current Discharge Characteristics Unit:A (25
,77 )
MSV 1000
2V 1000Ah
MSV 1000
Cells Per Unit
1
Voltage Per Unit
2
Capacity
1000Ah @ 10hr-rate to 1.80V per cell @25 (77 )
Weight
Approx. 64.4 kg(141.98 lbs)
Maximum Discharge Current
6000A(5sec)
Internal Resistance
Approx. 0.40 m
Operating Temperature Range
Discharge: -20 ~50 (-4 ~122 )
Charge: 0 ~40 (32 ~104 )
Storage: -20 ~40 (-4 ~104 )
Nominal Operating Temperature Range
25
3 (77
5 )
Float Charging Voltage
Recommended Maximum Charging Current Limit 300A
Equalization / Cycle Use Charging Voltage
Terminal
Container Material
Specification
The container and cover are made of flame retardant
plastics which meet ABS(UL 94-V0)
specifications.The oxygen index level is higher than 28
2.23 0.02/Cell at 25 (77 ) Temp.
Coefficient 3.3mV/ ( 1.8mV/ )
3.3mV/ ( 1.8mV/ )
2.35V Temps coefficient
Pb-Ca-Sn Alloy(L / Recessed Terminal)
years expected life under normal float charge.
As wit hall CSB batteries , all are rechargeable,
highly efficient , leak proof and maintenance free.
Powered by
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
339±3 (13.35±0.12)
331±3 (13.03±0.12)
171±3 (6.73±0.12)
471±3 (18.54±0.12)
F.V/Time
15MIN
30MIN
60MIN
2HR
3HR
4HR
5HR
6HR
8HR
10HR
1.60V
1423
979
648
383
288
228
193
168
133
113
1.67V
1298
933
618
370
273
220
185
160
130
110
1.70V
1206
910
608
363
270
218
183
158
128
108
1.75V
1052
839
560
343
253
206
173
150
123
103
1.80V
915
734
528
330
243
198
168
148
120
100
1.83V
795
649
488
310
233
188
160
140
114
97.5
F.V/Time
15MIN
30MIN
60MIN
2HR
3HR
4HR
5HR
6HR
8HR
10HR
1.60V
2332
1722
1153
693
520
418
353
310
250
210
1.67V
2134
1648
1150
688
513
413
350
308
248
208
1.70V
2033
1595
1113
673
503
410
348
303
243
205
1.75V
1842
1489
1040
643
483
393
333
290
238
200
1.80V
1679
1333
980
618
463
378
323
283
230
198
1.83V
1430
1156
903
580
443
360
308
270
220
190
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
ABS V0
(http://www.csb-battery.com)
by URS according to ISO 9001,ISO 14001.
The system of manufacturer was certified
RA1308
Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
