CSB Battery MSV500 User Manual
Msv 500, 2v 500ah, Powered by

is a long service life battery up to 15
Constant Power Discharge Characteristics Unit:W (25
,77 )
Constant Current Discharge Characteristics Unit:A (25
,77 )
MSV 500
2V 500Ah
MSV 500
Cells Per Unit
1
Voltage Per Unit
2
Capacity
500Ah @ 10hr-rate to 1.80V per cell @25 (77 )
Weight
Approx. 32.2 kg(70.99 lbs)
Maximum Discharge Current
3000A(5sec)
Internal Resistance
Approx. 0.40 m
Operating Temperature Range
Discharge: -20 ~50 (-4 ~122 )
Charge: 0 ~40 (32 ~104 )
Storage: -20 ~40 (-4 ~104 )
Nominal Operating Temperature Range
25
3 (77
5 )
Float Charging Voltage
Recommended Maximum Charging Current Limit 150A
Equalization / Cycle Use Charging Voltage
Terminal
Container Material
Specification
The container and cover are made of flame retardant
plastics which meet ABS(UL 94-V0)
specifications.The oxygen index level is higher than 28
2.23 0.02/Cell at 25 (77 ) Temp.
Coefficient 3.3mV/ ( 1.8mV/ )
3.3mV/ ( 1.8mV/ )
2.35V Temps coefficient
Pb-Ca-Sn Alloy(L / Recessed Terminal)
years expected life under normal float charge.
As wit hall CSB batteries , all are rechargeable,
highly efficient , leak proof and maintenance free.
Powered by
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
)
2
1
.
0
±
3
7
.
6
(
3
±
1
7
1
)
2
1
.
0
±
3
0
.
3
1
(
3
±
1
3
3
)
2
1
.
0
±
5
3
.
3
1
(
3
±
9
3
3
241±3 (9.48±0.12)
RA: 1206
Ratings are preliminary and subject to change.
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL924 and UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
(http://www.csb-battery.com)
by URS according to ISO 9001,ISO 14001.
The system of manufacturer was certified
ABS V0
F.V/Time 15MIN 30MIN 60MIN
2HR
3HR
4HR
5HR
6HR
8HR
10HR
1.60V
732
512
329
194
143
116
96.7 82.8
64.9
52.7
1.67V
664
494
326
191
140
114
96.5 82.6
64.6
52.2
1.70V
639
478
321
189
139
113
95.8 82.1
64.3
51.8
1.75V
577
460
310
186
136
111
94.5 81.2
63.9
51.2
1.80V
512
427
295
177
132
109
91.7 79.1
62.6
50.0
1.83V
442
382
268
163
125
102
88.4 75.9
59.6
47.2
F.V/Time 15MIN 30MIN 60MIN
2HR
3HR
4HR
5HR
6HR
8HR
10HR
1.60V
1223
894
588
367
274
213
180
156
125
102
1.67V
1149
870
581
364
272
210
178
154
124
101
1.70V
1118
850
575
361
270
209
177
154
123
100
1.75V
1038
810
561
352
267
202
176
153
122
99.2
1.80V
943
774
531
348
263
198
173
150
120
98.2
1.83V
834
699
496
327
248
191
170
147
117
95.9
