Polypropylene
(UL94-V0)*Flammability resistance can
be available upon request.
I2-Thread lead alloy recessed terminal to accept M6 bolt
13.5 to 13.8 VDC/unit Average at 25 (77 )
14.4 to 15.0 VDC/unit Average at 25 (77 )
Cells per unit
Voltage per unit
Capacity
Weight
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
Nominal Operating Temperature Range
Float Charging Voltage
Recommended Maximum Charging
Current Limit
Equalization and Cycle Service
Self Discharge
Terminal
Container Material
6
12
540W @ 15min-rate to 1.67V per cell @25
o
C(77
o
F)
Approx.43.9 kg(96.7 lbs)
800A(5sec)
Approx. 4
m
25
o
C±3
o
C (77
o
F±5
o
F)
54A
CSB Batteries can be stored for more than 6 months at
25
o
C (77
o
F). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
Discharge: -15 ~50 ( 5 ~122 )
Charge: -15 ~40 ( 5 ~104 )
Storage: -15 ~40 ( 5 ~104 )
Constant Power Discharge Characteristics Unit:W (25
,77 )
Constant Current Discharge Characteristics Unit:A (25
,77 )
HRL 12540W
12V 540W
Specification
Powered by
HRL 12540W is specially designed for high efficient discharge
application. Its characteristics are high energy density, small
footprint and high discharge efficiency. It can be used for more
than 260 cycles at 100% discharge in cycle service, up to 10
years in standby service.
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
275.7±2.5(10.85±0.1)
273.2±2.5 (10.76±0.1)
343±2.5 (13.5±0.1)
170±2 (6.69±0.08)
F.V/Time
2MIN
4MIN
6MIN
8MIN
10MIN
15MIN
20MIN
30MIN
60MIN
90MIN
1.60V
720
572
498
436
394
308
256
187
106
75.5
1.67V
608
517
452
406
370
294
245
181
105
74.3
1.70V
564
493
430
392
354
286
240
178
103
73.8
1.75V
501
440
398
365
327
270
228
172
101
72.0
1.80V
430
391
362
323
296
252
209
161
97.9
70.3
1.85V
379
340
304
282
265
222
187
147
90.3
66.2
F.V/Time 2MIN
4MIN
6MIN
8MIN
10MIN
15MIN
20MIN
30MIN
60MIN
90MIN
1.60V
6874
5883
5176
4688
4186
3421
2716
2057
1224
885
1.67V
6207
5325
4794
4282
3885
3250
2630
2006
1210
865
1.70V
5768
4937
4544
4016
3661
3097
2564
1988
1201
863
1.75V
5225
4639
4196
3766
3472
2951
2454
1925
1174
849
1.80V
4561
4310
3818
3442
3233
2723
2306
1846
1129
824
1.85V
4227
3643
3356
3146
3010
2443
2104
1715
1061
784
RA1311
Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
