CSB Battery HRL12280W User Manual
Powered by

Polypropylene(UL 94-HB) & Flammability resistance
of (UL 94-V0) can be available upon request.
I2-Thread lead alloy recessed terminal to accept M6/M8 bolt
13.5 to 13.8 VDC/unit Average at 25 (77 )
14.4 to 15.0 VDC/unit Average at 25 (77 )
Cells per unit
Voltage per unit
Capacity
Weight
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
Nominal Operating Temperature Range
Float Charging Voltage
Recommended Maximum Charging
Current Limit
Equalization and Cycle Service
Self Discharge
Terminal
Container Material
6
12
280W @ 15min-rate to 1.67V per cell @25
o
C(77
o
F)
Approx.25.8 kg(56.88 lbs)
800A(5sec)
Approx. 4
m
25
o
C±3
o
C (77
o
F±5
o
F)
28A
CSB Batteries can be stored for more than 6 months at
25
o
C (77
o
F). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
Discharge: -15 ~50 ( 5 ~122 )
Charge: -15 ~40 ( 5 ~104 )
Storage: -15 ~40 ( 5 ~104 )
Constant Power Discharge Characteristics Unit:W (25
,77 )
Constant Current Discharge Characteristics Unit:A (25
,77 )
HRL 12280W
12V 280W
Specification
Powered by
HRL 12280W is specially designed for high efficient discharge
application. Its characteristics are high energy density, small
footprint and high discharge efficiency. It can be used for more
than 260 cycles at 100% discharge in cycle service, up to 10
years in standby service.
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
213.9±2.5 (8.42±0.10)
210.5±2.5 (8.29±0.10)
261.0±2.5 (10.28±0.10) 168.5±2.0 (6.64±0.08)
F.V/Time
5MIN
10MIN
15MIN
20MIN
30MIN
40MIN
45MIN
50MIN
60MIN
90MIN
1.60V
318
216
167
137
103
82.6
76.0
70.1
59.9
44.6
1.67V
283
200
155
128
98.3
79.9
72.9
67.1
57.7
42.1
1.70V
266
192
149
124
96.3
78.1
71.2
65.4
55.6
40.6
1.75V
236
175
141
117
91.3
75.9
68.5
63.5
53.8
38.5
1.80V
207
161
131
111
85.4
70.5
63.7
58.8
50.1
36.3
1.85V
178
145
122
105
81.3
65.8
59.7
55.1
47.3
34.7
F.V/Time
5MIN
10MIN
15MIN
20MIN
30MIN
40MIN
45MIN
50MIN
60MIN
90MIN
1.60V
3,354
2,304
1,788
1,476
1,110
888
822
762
648
485
1.67V
3,036
2,166
1,700
1,417
1,079
876
804
738
636
466
1.70V
2,880
2,100
1,643
1,384
1,060
864
792
726
618
454
1.75V
2,615
1,955
1,575
1,326
1,023
834
780
703
600
436
1.80V
2,329
1,800
1,493
1,274
980
802
738
678
581
422
1.85V
2,016
1,656
1,408
1,212
938
760
694
636
550
404
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
RA1308
