CSB Battery HRL12200W User Manual
Powered by

Polypropylene(UL 94-HB) & Flammability resistance
of (UL 94-V0) can be available upon request.
I2-Thread lead alloy recessed terminal to accept M6 bolt
13.5 to 13.8 VDC/unit Average at 25℃ (77°F)
14.4 to 15.0 VDC/Unit Average at 25℃(77°F)
Cells per unit
Voltage per unit
Capacity
Weight
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
Nominal Operating Temperature Range
Float Charging Voltage
Recommended Maximum Charging
Current Limit
Equalization and Cycle Service
Self Discharge
Terminal
Container Material
6
12
200W @ 15min-rate to 1.67V per cell @25
o
C(77
o
F)
Approx.17.3 kg(38.1 lbs)
300A(5sec)
Approx. 5.3
m
25
o
C±3
o
C (77
o
F±5
o
F)
20A
CSB Batteries can be stored for more than 6 months at
25
o
C (77
o
F). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
Discharge: -15 ~50 ( 5 ~122 )
Charge: -15 ~40 ( 5 ~104 )
Storage: -15 ~40 ( 5 ~104 )
Constant Power Discharge Characteristics Unit:W (25
,77 )
Constant Current Discharge Characteristics Unit:A (25
,77 )
HRL 12200W
12V 200W
Specification
Powered by
HRL 12200W is specially designed for high efficient discharge
application. Its characteristics are high energy density, small
footprint and high discharge efficiency. It can be used for more
than 260 cycles at 100% discharge in cycle service, up to 10
years in standby service.
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
207.3±2.5 (8.16±0.10)
202.3±2.5 (7.96±0.10) 228.0±2.5 (8.98±0.10) 138.4±1.5 (5.45±0.06)
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
RA1312
Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
F.V/Time
5MIN
7.5MIN
10MIN
15MIN
20MIN
30MIN
40MIN
50MIN
60MIN
90MIN
1.60V
2448
2041
1745
1333
1098
816
659
556
476
343
1.67V
2306
1931
1666
1308
1083
809
656
554
475
342
1.70V
2207
1870
1625
1282
1066
796
648
553
474
339
1.75V
2022
1761
1523
1232
1027
772
638
542
464
335
1.80V
1840
1621
1409
1158
959
738
616
522
452
326
1.85V
1659
1418
1255
1035
873
687
576
490
423
310
F.V/Time
5MIN
7.5MIN
10MIN
15MIN
20MIN
30MIN
40MIN
50MIN
60MIN
90MIN
1.60V
243
197
164
123
98.9
71.9
57.7
48.5
41.8
29.9
1.67V
218
184
157
118
97.0
71.2
56.9
48.0
41.2
29.5
1.70V
209
175
151
116
95.7
70.3
56.6
47.8
41.1
29.4
1.75V
192
161
141
111
92.0
68.2
55.2
46.9
40.3
29.1
1.80V
165
145
126
102
85.2
64.6
53.2
45.0
38.9
28.2
1.85V
145
124
110
91.3
76.1
59.0
49.5
41.8
36.2
26.6
(http://www.csb-battery.com)
The system of manufacturer was certified
by TUV CERT according to ISO 9001,ISO 14001.
