I2-Thread lead alloy recessed terminal to accept M6 bolt
13.5 to 13.8 VDC/unit Average at 25 (77 )
14.4 to 15.0 VDC/unit Average at 25 (77 )
Cells per unit
Voltage per unit
Capacity
Weight
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
Nominal Operating Temperature Range
Float Charging Voltage
Recommended Maximum Charging
Current Limit
Equalization and Cycle Service
Self Discharge
Terminal
Container Material
6
12
150W @ 15min-rate to 1.67V per cell @25
o
C(77
o
F)
Approx.11.75 kg(25.9 lbs)
225A(5sec)
Approx. 7
m
25
o
C±3
o
C (77
o
F±5
o
F)
15A
CSB Batteries can be stored for more than 6 months at
25
o
C (77
o
F). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
ABS(UL 94-HB) & Flammability resistance of
(UL 94-V0) can be available upon request.
Discharge: -15 ~50 ( 5 ~122 )
Charge: -15 ~40 ( 5 ~104 )
Storage: -15 ~40 ( 5 ~104 )
Constant Power Discharge Characteristics Unit:W (25
,77 )
Constant Current Discharge Characteristics Unit:A (25
,77 )
HRL 12150W
12V 150W
Specification
Powered by
HRL 12150W is specially designed for high efficient discharge
application. Its characteristics are high energy density, small
footprint and high discharge efficiency. It can be used for more
than 260 cycles at 100% discharge in cycle service, up to 10
years in standby service.
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
172.0±2.0 (6.77±0.08)
--
195.6±2.0 (7.70±0.08)
130.0±1.5 (5.12±0.06)
F.V/Time
5MIN
7.5MIN
10MIN
15MIN
20MIN
30MIN
40MIN
50MIN
60MIN
90MIN
1.60V
169
138
116
86.7
69.6
50.4
40.0
33.5
28.9
20.8
1.67V
152
127
107
82.2
66.3
48.4
38.7
32.5
28.6
20.5
1.70V
144
122
103
80.0
64.7
47.5
38.0
32.1
28.4
20.4
1.75V
132
112
96.8
76.0
62.0
45.7
36.8
30.9
27.8
20.0
1.80V
119
104
90.0
71.1
58.4
43.8
35.1
29.8
26.8
19.5
1.85V
107
94.1
82.8
67.0
55.1
41.7
33.6
28.6
25.0
18.6
F.V/Time
5MIN
7.5MIN
10MIN
15MIN
20MIN
30MIN
40MIN
50MIN
60MIN
90MIN
1.60V
1,794
1,479
1,263
968
788
577
463
387
335
244
1.67V
1,624
1,370
1,182
935
753
559
451
386
334
239
1.70V
1,549
1,322
1,143
916
737
548
442
382
332
236
1.75V
1,422
1,234
1,075
877
704
530
428
374
325
231
1.80V
1,302
1,143
1,006
825
675
507
410
361
314
226
1.85V
1,188
1,057
943
773
639
486
396
337
296
222
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
(http://www.csb-battery.com)
by TUV CERT according to ISO 9001,ISO 14001.
The system of manufacturer was certified
RA1308
Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
