CSB Battery HRL12110W User Manual
Powered by

I1-Thread lead alloy recessed terminal to accept M5 bolt
13.5 to 13.8 VDC/unit Average at 25 (77 )
14.4 to 15.0 VDC/unit Average at 25 (77 )
Cells per unit
Voltage per unit
Capacity
Weight
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
Nominal Operating Temperature Range
Float Charging Voltage
Recommended Maximum Charging
Current Limit
Equalization and Cycle Service
Self Discharge
Terminal
Container Material
6
12
110W @ 15min-rate to 1.67V per cell @25
o
C(77
o
F)
Approx.9.9 kg(21.83 lbs)
225A (5sec)
Approx. 9
m
25
o
C±3
o
C (77
o
F±5
o
F)
11A
CSB Batteries can be stored for more than 6 months at
25
o
C (77
o
F). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
ABS(UL 94-HB) & Flammability resistance of
(UL 94-V0) can be available upon request.
Discharge: -15 ~50 ( 5 ~122 )
Charge: -15 ~40 ( 5 ~104 )
Storage: -15 ~40 ( 5 ~104 )
Constant Power Discharge Characteristics Unit:W (25
,77 )
Constant Current Discharge Characteristics Unit:A (25
,77 )
HRL 12110W
12V 110W
Specification
Powered by
HRL 12110W is specially designed for high efficient discharge
application. Its characteristics are high energy density, small
footprint and high discharge efficiency. It can be used for more
than 260 cycles at 100% discharge in cycle service, up to 10
years in standby service.
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
175.0±2.0 (6.90±0.08)
--
166.0±2.0 (6.54±0.08)
125.0±1.5 (4.93±0.06)
F.V/Time
2MIN
4MIN
6MIN
8MIN
10MIN
15MIN
20MIN
30MIN
60MIN
90MIN
1.60V
170
145
118
97.5
81.6
61.4
48.0
33.6
21.3
14.9
1.67V
151
129
108
91.1
77.5
59.6
47.0
33.2
20.8
14.7
1.70V
141
121
103
88.3
75.7
58.6
46.3
32.7
20.4
14.5
1.75V
125
108
93.2
82.7
72.2
56.1
44.7
32.3
20.0
14.4
1.80V
109
94.0
83.7
76.4
68.7
53.7
42.5
31.9
19.6
14.2
1.85V
89.3
78.7
73.6
69.2
64.4
51.0
40.8
29.7
18.3
14.0
F.V/Time
2MIN
4MIN
6MIN
8MIN
10MIN
15MIN
20MIN
30MIN
60MIN
90MIN
1.60V
1,806
1,541
1,270
1,053
888
682
554
385
247
174
1.67V
1,624
1,386
1,171
988
852
665
535
377
243
173
1.70V
1,530
1,316
1,107
956
827
655
526
372
239
171
1.75V
1,358
1,190
1,020
900
796
636
510
361
234
170
1.80V
1,177
1,054
941
851
764
610
495
352
229
168
1.85V
995
918
854
793
733
589
478
337
217
167
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
A
(http://www.csb-battery.com)
by TUV CERT according to ISO 9001,ISO 14001.
The system of manufacturer was certified
RA1308
Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
