CSB Battery HRL1280W User Manual
Hrl 1280w, 12v 80w, Powered by

I1-Thread lead alloy recessed terminal to accept M5 bolt
13.5 to 13.8 VDC/unit Average at 25 (77 )
14.4 to 15.0 VDC/unit Average at 25 (77 )
Cells per unit
Voltage per unit
Capacity
Weight
Maximum Discharge Current
Internal Resistance
Operating Temperature Range
Nominal Operating Temperature Range
Float Charging Voltage
Recommended Maximum Charging
Current Limit
Equalization and Cycle Service
Self Discharge
Terminal
Container Material
6
12
80W @ 15min-rate to 1.67V per cell @25
o
C(77
o
F)
Approx.6.5kg(14.33 lbs)
300A(5sec)
Approx. 9
m
25
o
C±3
o
C (77
o
F±5
o
F)
8A
CSB Batteries can be stored for more than 6 months at
25
o
C (77
o
F). Please charge batteries before using. For
higher temperatures the time interval will be shorter.
ABS(UL 94-HB) & Flammability resistance of
(UL 94-V0) can be available upon request.
Discharge: -15 ~50 ( 5 ~122 )
Charge: -15 ~40 ( 5 ~104 )
Storage: -15 ~40 ( 5 ~104 )
Constant Power Discharge Characteristics Unit:W (25
,77 )
Constant Current Discharge Characteristics Unit:A (25
,77 )
HRL 1280W
12V 80W
Specification
Powered by
HRL 1280W is specially designed for high efficient discharge
application. Its characteristics are high energy density, small
footprint and high discharge efficiency. It can be used for more
than 260 cycles at 100% discharge in cycle service, up to 8
years in standby service.
Width (W)
Dimensions :
Unit: mm (inch)
Overall Height (H)
Container height (h)
Length (L)
167.0±2.0 (6.57±0.08)
--
181.0±2.0 (7.12±0.08)
76.2±1.0 (3.00±0.04)
F.V/Time
2MIN
4MIN
6MIN
8MIN
10MIN
15MIN
20MIN
30MIN
60MIN
90MIN
1.60V
165
113
87.9
72.3
62.4
44.4
35.0
24.9
14.6
10.6
1.67V
142
103
81.7
69.5
58.7
43.5
34.0
24.6
14.4
10.4
1.70V
133
98.6
80.7
67.8
58.1
42.4
33.7
24.3
14.2
10.2
1.75V
119
92.3
75.5
64.3
54.3
41.6
32.9
23.7
14.0
10.1
1.80V
105
83.2
70.0
60.8
51.8
39.8
32.1
23.0
13.6
10.0
1.85V
92.3
76.6
65.2
56.8
49.2
37.6
30.1
22.1
13.5
9.84
F.V/Time
2MIN
4MIN
6MIN
8MIN
10MIN
15MIN
20MIN
30MIN
60MIN
90MIN
1.60V
1,584
1,171
955
790
691
496
391
282
169
122
1.67V
1,431
1,073
895
761
661
485
382
280
167
121
1.70V
1,369
1,045
884
743
660
475
381
275
165
118
1.75V
1,270
983
832
708
626
468
370
270
161
117
1.80V
1,173
909
781
679
593
453
364
266
159
116
1.85V
1,091
855
734
641
561
426
346
257
156
115
CSB-manufactured
VRLA
batteries are UL-
recognized components
under UL1989.
CSB is also certified by
ISO 9001 and ISO 14001.
(http://www.csb-battery.com)
by TUV CERT according to ISO 9001,ISO 14001.
The system of manufacturer was certified
RA1308
Ratings presented herein are subject to revision without notice. Please refer to www.csb-battery.com to confirm the latest version.
